Help CenterLG/LS INVERTER SSV004IE5-2C SV Series 100% Brand New
Related Products
-
LG/LS INVERTER SV004iC5-1 SV Series 100% Brand NewNegotiableMOQ: 1 -
LG/LS INVERTER SV004iC5-1F SV Series 100% Brand NewNegotiableMOQ: 1
-
LG/LS INVERTER SV008iC5-1 SV Series 100% Brand NewNegotiableMOQ: 1
-
LG/LS INVERTER SV008iC5-1F SV Series 100% Brand NewNegotiableMOQ: 1
-
LG/LS INVERTER SV004iC5-1F SV Series 100% Brand NewNegotiableMOQ: 1
LS Inverter IE5 series
Features
- LS Inverter IE5 series has smaller micro size.
- Easy operation and control.
- PI Control.
- LS Inverter IE5 series has modbus communication interface (optional).
- PNP, NPN dual control Signal..
- Parameter copy function.
- LS Inverter IE5 series is optimum solution for small size motor control.
Specifications
Application of LS Inverter IE5 |
ND: Fans, Pumps, HVAC |
Power supply |
1 phase 200 ~ 230; 3 phase 200 ~ 230 VAC (±10%) |
Rated capacity |
0.1-0.4kW (200 - 230 V) |
Rated current |
0.8-2.5 A (1 phase 200 ~ 230), 0.8-3.0 A (3 phase 200 ~ 230 VAC) |
Output frequency range |
0 - 200Hz |
Starting Torque |
- |
Overload current rating |
150% / 1Min |
Control Method |
V/f Control; PI Control |
Braking unit |
- |
Input |
Multifunction input terminal, frequency set power, frequency set(Volt/Current), frequency set common terminal |
Ouput |
Display; multifunctional relay |
Protection Function |
Over voltage, Under voltage, Over current, Ground fault, Drive overload, Overload trip, Overheat, Condensor overload, Phase loss overload protection, Frequency command loss, Hardware fault |
Main Control Functions |
- |
Communication |
RS-485 |
Peripheral Devices and Options |
AC input fuse, AC Reactor, DC Reactor. |
Degree of protection |
IP20 (open type) |
