Panasonic A5 Series Servo Motor MSMD012G1U Panasonic 100w Motor

Panasonic A5 Series Servo Motor MSMD012G1U Panasonic 100w Motor thumbnail-1
Panasonic A5 Series Servo Motor MSMD012G1U Panasonic 100w Motor photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2004
Annual Export Value:
Above US$100 Million
Contact Supplier Request Quote Chat Now
Brisynergy Automation Pte. Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Panasonic A5 Series Servo Motor MSMD012G1U Panasonic 100w Motor



Brisynergy specializes in providing automation equipment products

Main products:

PLC, Servo Motor, Inverter, HMI, Sensor and others

Main Brand:

Mitsubishi, Fuji, Yaskawa,Panasonic, Siemens, Omron, Allen Bradley, Proface, ABB and others

Ms Dora (Sales Manager) Skype: brisynergy03







Brand Name :Panasonic
Output (W) :100
Application Driver Standard Type :MADHT1505
Application Positioning Type :MADHT1505E
Input Power Supply :Single phase/3-phase 200V
Rated Speed (RPM) :3000
Rated Torque(Nm) :0.32
Frame Size :A
Inertia Ratio (x 10-4 kg � m2) :0.051
Encoder Resolution :20-BIT Incremental

Software Download :Acservo-panasonic











Model No. Output Specification
MSMD5AZG1U   50W 20bit Inc/lead line
MSMD5AZG1V   20bit Inc/Lead line/with Brake
MSME5AZG1U   20bit Inc/Connector
MSME5AZG1V   20bit Inc/Connector/with Brake
MADHT1505   All in one Amplifier
MADHT1505E   Pulse Amplifier
MSMD012G1U   100W 20bit Inc/lead line
MSMD012G1V   20bit Inc/Lead line/with Brake
MSME012G1U   20bit Inc/Connector
MSME012G1V   20bit Inc/Connector/with Brake
MADHT1505   All in one Amplifier
MADHT1505E   Pulse Amplifier
MSMD022G1U   200W 20bit Inc/lead line
MSMD022G1V   20bit Inc/Lead line/with Brake
MHMD022G1U   20bit Inc/lead line
MHMD022G1V   20bit Inc/Lead line/with Brake
MSME022G1U   20bit Inc/Connector
MSME022G1V   20bit Inc/Connector/with Brake
MADHT1507   All in one Amplifier
MADHT1507E   Pulse Amplifier
MSMD042G1U   400W 20bit Inc/lead line
MSMD042G1V   20bit Inc/Lead line/with Brake
MHMD042G1U   20bit Inc/lead line
MHMD042G1V   20bit Inc/Lead line/with Brake
MSME042G1U   20bit Inc/Connector
MSME042G1V   20bit Inc/Connector/with Brake
MBDHT2510   All in one Amplifier
MBDHT2510E   Pulse Amplifier
MSMD082G1U   750W 20bit Inc/lead line
MSMD082G1V   20bit Inc/Lead line/with Brake
MHMD082G1U   20bit Inc/lead line
MHMD082G1V   20bit Inc/Lead line/with Brake
MSME082G1U   20bit Inc/Connector
MSME082G1V   20bit Inc/Connector/with Brake
MCDHT3520   All in one Amplifier
MCDHT3520E   Pulse Amplifier
MDME102G1G   1KW MDME 20bit Inc/lead line
MDME102G1H   20bit Inc/Lead line/with Brake
MDDHT3530   All in one Amplifier
MDDHT3530E   Pulse Amplifier
MDME152G1G   1.5KW MDME 20bit Inc/lead line
MDME152G1H   20bit Inc/Lead line/with Brake
MDDHT5540   All in one Amplifier
MDDHT5540E   Pulse Amplifier
MDME202G1G   2KW MDME

20bit Inc/lead line
MDME202G1H   20bit Inc/Lead line/with Brake
MEDHT7364   All in one Amplifier
MEDHT7364E   Pulse Amplifier
