Product Description
HB965 length distance measuring six digits counter cutting measurement set control
Note: if you want the HB961 with trasmission or communication, please feel free to contact me or send me inquiry.
Characteristics
By setting the meter counting mode, the meter can realize up and down counting, and can recognize the phase counting function.
External photoelectric pair tube, proximity switch, grating sensor, encoder, etc.
Alarm value, count value. Set value is not lost when power is off
Set two alarm values, two relays independently output
Analog current transmission output, RS485 communication output
Technical parameters
1. Working power: AC / DC 85 ~ 260V (other power can be customized)
2. Measurement frequency: 10KHz
3. Display range: -199999999999
4. Trigger mode: low level trigger (trigger on the falling edge of the switch contact)
5. Display value: Display value = input value × magnification A ÷ magnification b + initial value C
6. Magnification range: magnification A: -199999 ~ 999999 times B: 1 ~ 999999
7. Contact capacity: AC250V/3A (resistive load)
8. Contact life: 105 times
9. Feed output: DC24V; DC5V; DC30mA
10. Transmitting output: 0~20mA; 4~20mA
11. Transmission accuracy: 0.2% FS
12. Communication output: RS485 (optical isolation) MODBUS_RTU protocol
13. Dimensions: 96 × 48 × 82 mm
14. Opening size: 92×44mm
15. Use environment: 0 ~ 50 ° C; ≤ 85% RH
