NPN open collector absolute type encoder TRD-MA512N
Cautions for use
Do not wire the cable in parallel with other power lines and do not share a duct with other cables. „ Use capacitors or surge absorption elements to remove the sparks caused by relays and switches in the control panel as far as possible. „ Be sure to connect all wires properly, as wrong wiring can damage the internal circuitry. „ Use a specified coupling for connecting the encoder shaft and the shaft of a machine to be controlled. Do not squeeze the shaft into the coupling. „ The service life of the bearing is largely affected by the amount of load to the shaft. Try to reduce the load as much as possible. „ Do not disassemble the product. „ As the rotary encoder is composed of precision parts, its function will be impaired when it is subjected to shocks. Use sufficient care for handling and mounting.
