digital time display relay JS11S 24v 36 110v 220V AC with SPDT
Brief: JS11S series time relay is suitable for AC 50Hz, rated control power supply voltage 380V and below or DC rated control power supply voltage 220V or below as delay components, turn on or break the circuit at a predetermined time.
Working condition:1. Use environment: the height of sea disturbance does not exceed 2000 meters, the surrounding environment temperature is not higher than + 40C and not less than 5C.
(2) the range of power supply voltage is 85% ≤ 110% rated voltage.
3. In a medium free of serious vibration and explosion risk, and in which there is no gas and dust sufficient to corrode metal and destroy insulation; in places where rain and snow do not strike.4. Install vertically or horizontally.
5. Pollution level: pollution level 3.
JS11S wiring diagram
JS11S-A wiring diagram
JS11S-05~07/M wiring diagram
JS11S-05~07 /MS wiring diagram
Shape and dimension
