Help CenterCALT Sensor CWP-S1000 Rope Encoder Draw Wire Displacement Sensor
Related Products
-
2000mm Draw Wire Displacement Sensor Analog Output Type Rope Encoder Wire EncoderNegotiableMOQ: 1 -
2000mm Length Distance Measuring Device Potentiometer Analog Displacement SensorNegotiableMOQ: 1
-
Potentiometer 400mm Stoke Range Displacement Sensor 4~20mA Output for Length Measuring(sensor)NegotiableMOQ: 1
-
CALT 24 Volt String Potentiometer Sensor Pull Wire Displacement Sensor Position SensorNegotiableMOQ: 1
-
CALT 2000mm 4-20mA Stoke Pull Wire Displacement Encoder String Pot Draw Wire Position SensorNegotiableMOQ: 1
CALT sensor CWP-S1000mm draw-wire position compact size rugged construction and easy to install
*compact size, rugged construction, easy to install
*economic cost, and cost savings for customers
* Various signals output optional: push-pull, TTL, open collector and so on
*The cylinders, testing machines and other industry has achieved large-scale applications, reliability
Feature
Internal absolute code disk. Digital valued. Signal is resistant from temperature and mechanical movement. No zero drift.
Modbus RTU output.
Each lap 12 high resolution encoder, 4096 times in a row, working range.
Direction setting External setting line can preset the position. Convenient installation and no need positioning.
Wide working voltage ,low power consumption.
Clamping flange or synchronous flange.
1. Model Selection Help
Please leave the output you want, If you want to place order through this product directly.
Or send inquiry to us for help to select correct model.
2. Discount
Bulk quantity can enjoy good discount , Please contact us.
3. After service
If you have any related technical questions , our engineers are happy to answer.
COMPANY PROFILE
Shanghai QiYi Electrical & Mechanical Equipment Co., Ltd is a technology industrial enterprises integrating R & D, production, agency and sales. our company focus on the rotary encoders, displacement sensors and proximity sensor with CALT brand. We have many years of experience in supplying rotary encoders and sensors, which widely used in CNC machine, steel rolling machinery, linear guide systems, hydraulic systems, lifting machinery, turbine and other multiple industries. Located in Shanghai, we enjoy convenient air, water and land transportation.
