2020 Automatic Zipper Premade Bags Filling Sugar Candy Dried Vegetables Horizontal Packing Machine With 5 Years Warranty photo-1
2020 Automatic Zipper Premade Bags Filling Sugar Candy Dried Vegetables Horizontal Packing Machine With 5 Years Warranty photo-2
2020 Automatic Zipper Premade Bags Filling Sugar Candy Dried Vegetables Horizontal Packing Machine With 5 Years Warranty photo-3
2020 Automatic Zipper Premade Bags Filling Sugar Candy Dried Vegetables Horizontal Packing Machine With 5 Years Warranty photo-4
2020 Automatic Zipper Premade Bags Filling Sugar Candy Dried Vegetables Horizontal Packing Machine With 5 Years Warranty photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2012
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
The Marked Prices Of Our Products Are All Range Prices Of The Entire Product Series.
If You Need a Detailed Quotation, Please Send An Inquiry At The Bottom Of The Page.
Attention: 1 --- All prices and parameters shown above are automatically generated by the system, if you want to know the exact information, please click "Contact Supplier" to send mail to us. 2 --- Because of the time difference, we suggest that you can choose to send us an inquiry instead of online chat. 3 --- When sending us an enquiry or message, please tell us your Email or WhatsApp/Wechat/Skype .etc, then our sales manager can contact you quickly.
HorizonTop-series Horizontal Packaging Machine HorizonTop-series Horizontal Packaging Machine is suitable for filling different products such as powder, granule, candy, tablets, liquid, viscous liquid, cream etc. It is applied to a wide range of packages, such as pre-made Pouch, stand up pouch, zipper pouch, spouted pouch, and shaped pouch etc.Up to 15kg can be filled It can complete pouch forming, feeding, measuring, filling, sealing, date printing, nitrogen filling, counting, finished product delivery. Full servo technology machine ,fast in packing, stable in operating, Low noise, Food grade 304 stainless steel, easy to clean, easy to maintain, durable machine with reasonable price.
Technical Parameters
Model
HorizonTop--210
HorizonTop--250
HorizonTop--360
HorizonTop--500
Speed
30-50 bags/min
30-45 bags/min
15-35 bags/min
3-15 bags/min
Accuracy
± 1.5%
± 1.5%
± 1.5%
± 1.5%
Bag width
55-200mm
80-250mm
120-350mm
120-400mm
Bag height
100-280mm
100-280mm
100-280mm
150-500mm
Max packaging capacity
1-5kg
1-5kg
1-5kg
1-15kg
Power
4kw
4kw
4kw
4kw
Gas consumption
0.6m3/min
0.6m3/min
0.6m3/min
0.6m3/min
Air pressure value
0.6MPa
0.6MPa
0.6MPa
0.6MPa
Weight
1450kg
1700kg
2200kg
800kg
Size（mm）
2900*1000*1390
3500*1000*1390
3900*1000*1390
2300*1000*1390
Warranty
5 years
5 years
5 years
5 years
Hot Tip
All of our machines support customization, and installation of two filling heads at the same time, filling speed is faster. Send an inquiry for more information.
Features
1.Horizontal single axis driven easy for maintenance & clean.
2.PLC+Touch screen for convenient opeartions.
3.If pouch not full open, no fill, no seal.
4.With combination scale, auger filler, pump filler for various product, accuracy weighing scale filler, combination accuracy weighing, collect hopper for increase speed.
5.Servo driven powder filling, dust collector for proof powder.
Product Details
Scale
Each adjustment station has a scale, so that the size can be adjusted quickly when filling bags of different specifications.
Food grade 304 stainless steel and Pharmaceutical grade painting
The main parts are made of food grade 304 stainless steel, corrosion-resistant and rust free.
The painting of the whole rack reaches the drug grade.
Dividing box
Indexing box running spindle, vibration only 3 microns, almost no vibration.
The noise is low when the machine is running at high speed.
LED lights
There is an LED light on the back, so we can see it more clearly during maintenance.
Waterproof trough
There is a waterproof trough on the back, so we can wash the whole body directly with water.
Processing Workshop
More Products
Company Profile
Our Company
Since year 1996, LTPM CHINA had started manufacturing and supplying Pharmaceutical and food packaging machines such as Bag packaging system, Bottling Line, Liquid filler, Blister machine, Capsule filling machine, Liquid Filler, Cartoner, etc.
LTPM CHINA designs and manufactures different types of packaging lines for customers, including standard or non-standard models.
We have now 12 engineering technical person for technology improvement. Serve better and Offer the best industrial Solution always become our target.
Our Machinery Manufacturing Workshop
Imported CNC Machining Centre makes all parts process accurate. Own R&D team with more than 20 years engineering expereince, can customize the equipment and packaging line to your satisfaction.
Professional Business Team
Warm, professional business team, careful response to your inquiry, timely response rate of more than 93%, higher than the average level of the industry.
Our Certificates
ISO, CE, SGS, BV Certified Company.
Packing & Shipping
All machine delivery with anti rust spray, film wrapping and Sea shipping affordable wooden box.
FAQ
Q: How many different type of bags your machine can work with? A: Four side seal Pouch, Three side seal pouch, back side seal pouch, Zipper Bag, Self Stand Up Pouch, Irregular Premade bags, etc.
Q: How many different product your machine can work with? A: Our machine can work for all kinds of products that client want to pack into Premade Bags by changing Feeder. Such as, Liquid, Paste, Powder, Granular, Biscuits, Rice, pop corn, Sea food, cosmetic, etc.
Q: What we should do when we have different sizes of bags, do we need any change parts? A: No need to buy any change parts. Before we ship the machine to client, we will commission the machine with all different product sample from client, then save the data as a receipt in PLC. When the client is going to use different sizes, just read out the data, then the machine will have the correct size to catch the bag.
Q: what is your annually production capacity for Rotary Packing Machine?
A: We ship More Than 20sets rotary packing machine every month, totally around 300sets per year. We are expanding our facility in 2020, aim for 500sets in 2021. Our clients include Pharmaceutical Factory, Food factory and Cosmetic factory.
Q: What is the warranty period for your machine?
A: 5 years free warranty.
