Low price energy conservation intensity RLY360 Oil Combustion Hot Air Furnace for Tea
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
2018 hot sale Pharmaceutical ZS Series Granules/particle Vibrating Sieve
-
Stainless steel industrial dryer 50KG three-legged centrifuge hardware plastic food multi-function dehydrator Centrifuge
-
Flexible shaftless small screw conveyor for powder/sand concrete/grain
-
PLG series continuous organic chemical drying plate drying equipment
-
PLG High Efficiency Continuous Disc Plate Dryer for Ceftriaxone/cefotaxime/CTX
-
vertical rotary tray dryer drying machine for waste sludge
Product Description
Product Description
Low price energy conservation intensity RLY360 Oil Combustion Hot Air Furnace for Tea
WORKING PRINCIPLEThe fuel is burnt at the burner to produce high temperature gas. The heat will conduct to the air by the heat exchange device. The temperature of the high temperature gas will dropped to less than 250℃ and then discharged. The clean air is pushed to hot air furnace by the blower. The hot air will be sent from the vent after absorbed heat up to the rated value. When the temperature of hot air reaches the rated upper limit, the burner will stop burning or turn down to a small fire automatically. When the temperature of hot air drops to the rated low limit, the burner start to burn or turn up to a big fire automatically.
APPLICATION
This furnace is widely used for curing, heat-setting, and drying in various industries such as pharmaceutical, chemical, food,textile, food processing, wood processing, automobile, and etc.
Specification
Model | Burner | Oil Combustion kg/h | Capacity 104kcal/h | Overall Dimension L×W×H mm | Hot Air Inlet L×W mm | Total Weight kg |
RLY1 | RIELLO.G3/DL3FS | 1.3-1.6 | 1 | 1200×1200×1600 | Φ200 | 460 |
RLY4 | RIELLO.G10/DL10FS | 5-6.5 | 4 | 1700×1300×1600 | Φ250 | 850 |
RLY10 | RIELLO.G20/DL23FS | 13-16 | 10 | 2300×1568×1870 | Φ300 | 2200 |
RLY20 | RIELLO 1G/DL34FS | 26-32 | 20 | 2800×1568×1870 | Φ400 | 2670 |
RLY30 | RL50/DL55FT | 39-48 | 30 | 3400×1568×1870 | Φ450 | 3060 |
RLY40 | RL70/DL75FT | 52-64 | 40 | 4440×1768×2070 | Φ550 | 5600 |
RLY60 | RL100/DL100FT | 78-96 | 60 | 5140×1868×2070 | Φ600 | 8460 |
RLY100 | PRESS 4G/DL 120FT | 130-140 | 100 | 6440×2480×2300 | 550×600 | 12800 |
RLY160 | P300/DL250FT | 200-270 | 160 | 7470×2920×3480 | 750×900 | 15780 |
RLY200 | P300/DL300FT | 260-300 | 200 | 8175×2920×3480 | 750×900 | 18500 |
RLY360 | G1510 | 480-620 | 360 | 9300×2920×3480 | 21000 |
