Product Description
Low price PLC control ZPG-1000 Vacuum Harrow Dryer for traditional Chinese medicine
This dryer is widely used in pharmaceutical industry, foodstuff industry, chemical industry and etc. Especially suitable for the following materials:1. Pulpiness, paste-like mixture or powder materials.
2. Thermal sensitive material which required to be dried at lower temperature.
3. Materials that are easy to oxidize or explode and the material that have strong irritative or toxic.
4. Materials that required recovering solvent.
Working principle
ZPG Vacuum Harrow Dryer is an innovation horizontal batch-type vacuum dryer improved on the basic of introduced technology of harrow dryer.
The moister of wet material will be evaporated by heat transmission. The stirrer with blade will remove material on hot surface and move in the container to form cycle flow .The evaporated moisture will be pumped by vacuum pump.
The moister of wet material will be evaporated by heat transmission. The stirrer with blade will remove material on hot surface and move in the container to form cycle flow .The evaporated moisture will be pumped by vacuum pump.
Technical parameters
Item
|
Model |
||||||||||||
Unit |
ZPG-500 |
ZPG-750 |
ZPG-1000 |
ZPG-1500 |
ZPG-2000 |
ZPG-3000 |
|||||||
Working Volume |
L |
300 |
450 |
600 |
900 |
1200 |
1800 |
||||||
Heating Area |
m2 |
6 |
7.6 |
9.3 |
12.3 |
14.6 |
19.3 |
||||||
Stirring Revolution |
rpm |
6-30stepless variable |
|||||||||||
Power |
kw |
4 |
5.5 |
5.5 |
7.5 |
11 |
15 |
||||||
Design pressure of Jacket(Hot water)) |
MPa
|
≤0.3
|
|||||||||||
Vacuum Degree
(Inside of the cylinder)
|
MPa
|
-0.09～0.096
|
|||||||||||
Product features
1. This dryer adapted the interlayer heating technology. The heat conducting area is large and the heat efficiency is high.
2. This dryer is equipped with stirring device; it keeps the raw material in a continuous circling status inside of the cylinder so the heating uniformity is improved greatly.
3. With the stirring functions, the dryer can easily dry the pulpiness, paste-like mixture or powder materials.
2. This dryer is equipped with stirring device; it keeps the raw material in a continuous circling status inside of the cylinder so the heating uniformity is improved greatly.
3. With the stirring functions, the dryer can easily dry the pulpiness, paste-like mixture or powder materials.
