Thin Section Bearing KC045AR0 Angular Contact Ball Ring 4.5*5.25*0.375 in 114.3*133.35*9.525 mm for Robot Joint
KC045AR0/CSEC045 Thin section angular contact ball bearing belongs to KC SERIES of thin section ball bearings, the KC SERIES include KCCP0, KCXP0 and KCAR0,which represented : Type-C : Deep Groove bearing, Type-X: Four Point Contact bearing and Type-A: Angular Contact bearing, the rolling body of these bearings is ball, which can be nylon ball or steel ball as requested. The bore size of KC SERIES are ranged from 4 inches to 20 inches and the outer diameters are arranged from 4.75 inches to 20.75 inches, while the Cross Section is constant, that is 0.375 inch.
Parameters:
Bearing Type Ball
For Load Direction Angular
Construction Single Row
Contact Angle 25°、30°
Seal Type Open
Cross Section 3/8″ x 3/8″
Part Number KC045AR0(NKC045AR0)
Bore Dia (d) 4.500"(114.3mm)
Bore Dia Tolerance -0.0008"– 0"
Outer Dia (D) 5.250”(133.35mm)
Outer Dia Tolerance -0.0008"– 0"
Width (B) 0.375"(9.525mm)
Width Tolerance +.000 –.005"
Ring Material 52100 Chrome steel
Ball Material 52100 Chrome steel
Cage Material Brass
Dynamic(lbs) Radial 1234
Thrust 2990
Static (lbs) Radial 2860
Thrust 8270
Lubrication Lubricated
Temperature Range -20° to 180 ℃
ABEC Rating ABEC-1
Radial Clearance 0.0000 – 0.0005"
Weight (lbs) 0.490
About Our Stock
For those items are available in the warehouse, we shall deliver them within 7 days upon receiving payment, and those are not available , we shall arrange to produce them however a minimum order is required, and the lead time shall be around 10-30 days.
Applications:
Our BOBI products are widely used in the following fields:
Medical Equipment, Rotary polishing equipment, X-ray – MRI, Rotary pipe cutting equipment, Rotary welding equipment, Semi-conductor equipment, Rotary actuators, Rotary work holding tables, Aerospace - auxiliary equipment, Turrets, Gun turrets, Turntables, Indexing tables, Missile launchers, Machine tools, Lathe accessories, Radar equipment, Robotics, Radar drives, Antenna pedestals, Packaging equipment, Satellite antennas, Pedestals Labeling machines, Truck mounted communication equipment, Food processing equipment, Bottling equipment.
