Description:
Hall effect sensor can be used to sense the speed and position of a rotating motor.
The DC motor speed sensors are based on using the Hall element to sense the change influx in the air gap between a magnet and a notch in a rotating shaft. The main advantage of Hall effect speed sensors is that they are a non-contact sensor that is not limited by mechanical wear. The circuitry inside the sensor typically consists of a pulse counter to provide an output signal that can be directly connected to the motor controller.
Specifications:
Model: NOCO-SS-2020
Applied to: AMD (KDS) DC motors (speed sensor / encoder, widly used in Club Car, EZGO, John Deere, Eagle and Lvtong golf carts and mobility vehicles)
Operating temperature range: -50°C to +125°C
Connector: DT triangle type or AMP flat type 3-Pin waterproof connect
Wiring (example: DC SepEx Motor Controller Assemblage, Model: 1268-5403):
Red wire: power +
Black: power -
Green: speed signal
Installation position: rear end of motor (see example: XP-2067-S DC SepEx motor or ZSQ48-3.8-T DC SepEx motor. Please pay attention to the difference of connectors.)
Package:Normally we use the standard exporting packaging. We also can according to clients' request .
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperating.
2. By Air: Delivery from the Shanghai airport to customer's destination city air port.
3. By Sea: Delivery from the Shanghai sea port .
Q1. Can I have a sample order?
A: yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Sample needs 3-5 days.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Q8: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less
than 0.2%
