Electric Car Mini Bus Conversion Kits 5kw dc Controller 36v 1204 1204M

CURTIS Model: 1204M-5203
Norminal Battery Voltage (Volts): 48V (default setting) or 36V
2 Minute Current Rating (amps): 275
5 Minute Current Rating (amps): 200
1 Hour Current Rating (amps): 125
Plug Braking (A2 Busbar): Yes
PWM operating frequency: 15.6 kHz
Electrical isolation to heatsink (min.): 500 VAC
KSI input current (no contactors engaged):
70 mA without programmer
130 mA with programmer
Logic input current: < 2 mA
Status LED output current (max.): < 2 mA

Ten throttle types can be used with these controllers:
Type 0: 2-wire potentiometer, 0–5kΩ
Type 1: 2-wire potentiometer, 5kΩ–0
Type 2: single-ended 0–5V input
Type 3: 2-wire potentiometer, 4.6kΩ–0
Type 4: 2-wire potentiometer, 5.5kΩ–0
Type 5: 2-wire potentiometer, 1kΩ–0
Type 6: ITS input
Type 7: single-ended 6.3–10.6 V input
Type 8: single-ended 6–12 V input
Type 9: single-ended 3-wire potentiometer, 0–5kΩ
Dimensions: L173xW146xH77 mm
Operating ambient temperature range: -40°C to 50°C
