Help CenterCurtis Programmable DC Motor Controller 1207b-5101 24V-300A for Personnel Carriers
Related Products
-
Excellent Manufacture Curtis DC Compound Motor Controller 1207B-5101 24V-300ANegotiableMOQ: 1 -
Intelligent Curtis DC Motor Controller 1205M-6B403 60V/72V-400ANegotiableMOQ: 1
-
Curtis Brushed DC Motor Controller 1205M-6B403 60V/72V-400A for Personnel CarriersNegotiableMOQ: 1
-
Golf Cart Parts Curtis Programmable DC Motor Remote Controller 1205M-6B403 60V/72V-400ANegotiableMOQ: 1
-
Club Car DC Motor Speed Controller Curtis 60V/72V-400A Controller 1205M-6B403NegotiableMOQ: 1
* CURTIS Model |
1207B-5101 |
||||||
* Norminal Battery Voltage (Volts) |
24V |
||||||
* Maximum operating voltage |
30 V |
||||||
* Overvoltage point |
33 V |
||||||
CURTIS PMC 1207B-5101 programmable motor speed controllers are the latest upgraded version of popular 1207B-5101 controllers. The CURTIS 1207B-5101 programmable motor speed controller provides efficient, cost-effective, and simple-to-install control for a variety of small electric vehicles. Typical applications include walkie fork/pallet trucks, mini personnel carriers, and sweepers. The microprocessor-based logic section combined with a proven MOSFET power section gives the 1207B-5101 controller high power and advanced features in a simple, compact package.
Specifications:
Nominal input voltage: 24 V
PWM operating frequency: 15 kHz
Electrical isolation to heatsink (min.): 500 VAC
KSI input voltage: 16 – 30 V
KSI input current (typical):
80 mA without programmer
130 mA with programmer
Logic input current (typical): 10 mA at 24 V
Logic input threshold: 8 V
Ambient operating temperature range: -25°C to 50°C
Heatsink overtemperature cutback: 85°C
Heatsink undertemperature cutback: -25°C
Package: splash resistant
Hefei Huanxin Technology Develop Co., Ltd. has been devoting ourselves to developing and manufacturing and other since 2004. We are located in Hefei, Anhui Province, with convenient transportation access. We employ over 101 - 200 People staff members. We have achieved great improvement since our company was founded in 2004. We abide by the motto of First-class quality, Reasonable price, Best service and Professional product support.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Package:Normally we use the standard exporting packaging. We also can according to clients' request .
Shipping :
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier we are co-operating at present.
2. By Air: Delivery from the Shanghai airport to customers' destination city air port.
3. By Sea: Delivery from the Shanghai sea port .
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.
Q6. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty for our products.
Q8: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%.
