BN-NIR-256X1 256x1 InGaAs Linear Sensor
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2004
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BN-NIR-512X2 512x2 InGaAs Linear Sensor 0.9-1.7NegotiableMOQ: 1 -
BN-NIR-800X2 800x2 InGaAs Linear SensorNegotiableMOQ: 1
-
BN-NIR-1024X2 1024x2 InGaAs Linear Sensor 0.9-1.7NegotiableMOQ: 1
-
BN-TU-I 320x256 Shortwave Infrared InGaAs Sensor 0.9-1.7NegotiableMOQ: 1
-
BN-HU-I 640x512 Shortwave Infrared InGaAs Sensor 0.9-1.7NegotiableMOQ: 1
Specification
item |
value |
Model Number |
BN-NIR-256X1 |
Type |
InGaAs shortwave infrared sensor |
Place of Origin |
China |
Zhejiang |
|
Brand Name |
BAINEL |
Usage |
Imaging |
Theory |
Shortwave infrared |
Output |
SWIR |
Description |
InGaAs shortwave infrared sensor |
Details Images
Products Description
Application Fields:
Near infrared spectrometer
Product features:
Positive irradiation structure, high aspect ratio photosensitive surface, high sensitivity, internal integrated thermoelectric
Performance Parameter
Format |
256X1 |
||||||
Photosensitive Surface Size |
50μm x 500μm |
||||||
Pixel Pitch |
50μm |
||||||
Spectral Response |
0.9~1.7μm |
||||||
Peak Detection Rate |
≥1 x 10^12 cm.Hz^1/2/W @5℃ 1.55μm |
||||||
Quantum Efficiency |
≥80% |
||||||
Non Uniformity Without Correction |
≤5% |
||||||
Blind Element Rate |
≤0.5% |
||||||
Dynamic Range |
≥70dB |
||||||
Operating Temperature |
-20 ~ +60℃ |
||||||
Storage Temperature |
-40 ~ +70℃ |
||||||
Dimension |
55 mm (L)×30 mm (W) ×10 mm (H) |
||||||
Packaging Characteristics |
Internal integrated thermoelectric cooler, metal tube shell airtight package |
||||||
Remark:
(1) During the use of the product, anti-static protection is required, and the operator shall wear an electrostatic bracelet.
(2) during storage and transportation, products should be placed in antistatic foam and stored in an antistatic box.
(3) The pins shall not be inserted or inserted with excessive force, and the pins shall not be bent more than 45 ° along the root to prevent the glass beads from cracking due to bending.
(4) The product needs to be plugged in and out after power failure.
