WD-12 Water bath nitrogen blowing sample concentrator
WD-12 sample concentrator consists of a base and stand assembly, sample holder and gas distribution system. Test tubes are held in place by a spring-loaded sample holder and support tray. Each position is numbered.
The gas passes through an adjustable flow meter to the distribution manifold. Flexible tubing leads to valve-tube assemblies at each position. Depending on the test-tube size and solvent volume they can be individually raised or lowered to the correct height. Needles blow gas onto the surface of the solution resulting in rapid evaporation of the solvent. All materials used are laboratory quality and can withstand contact with organic solvents.
The round, stainless steel water bath is thermostatically controlled and will accurately maintain water temperature from ambient temperature to 99℃.
Features of water bath nitrogen blowing instrument
Technical parameters of laboratory water bath nitrogen blowing concentrator
| Model | WD-12 |
| Temperature control range | RT.+5°C~99°C |
| Temperature control accuracy | ±1°C |
| Tube size | 10-29mm |
| Beaker / Tube size | <Φ30mm |
| Gas flow | 0-15L/min |
| Nitrogen Consumption | 330ml/min |
| Needle Length | 150mm |
| Accommodates samples | 12pcs |
| Inner dimension | Φ260x150mm |
Accessories for WD-12 water bath sample concentrator
| No | Description |
| 01 | WD-12, AC220V/AC120V, 50/60Hz, 1000W |
| 02 | 150mm neeedles(just for KD200 and WD-12) |
