Good Price 5L 10L 20L 50L 100L 200L Laboratory Industrial Chemical Jacketed Reactor Vessel
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2016
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5l 10l 30l 30 L 100l 5 50 100 Liter 200l Lab Industrial Vacuum Jacketed Glass ReactorNegotiableMOQ: 1 -
Jacketed Glass Reactor 1L 2LNegotiableMOQ: 1
-
LAB1ST 1L 10L 20L 30L 100L 200L Sealed Chemical Double Layers Jacket Jacketed Glass ReactorNegotiableMOQ: 1
-
5L 10L 100L 50 Liter Jacketed Glass Chemical Plant Reaction VesselNegotiableMOQ: 1
-
LAB1ST OEM 50L 100L 200L Multifunctional Stainless Steel Decarboxylation Decarboxyl Evaporation Jacketed ReactorNegotiableMOQ: 1
Labfirst Scientific (LAB1ST) Was Founded and Based in Shanghai, Committed to Providing First-class Equipment for Customers in the Chemical and Pharmaceutical Industry. Our Product Lines Range from Laboratory & Pilot Scale to Industrial Scale and Mainly Focus on the Fine Chemicals, Biological Fermentation, Plant Extraction and Other Related Fields, to Provide All Kinds of Equipment and Turnkey Solutions.
Our Team
Office in China
Warehouse in USA
Warehouse in China
Products Description
Model |
JGR-1L |
JGR-2L |
JGR-5L |
JGR-10L |
|||
Electrical Requirements |
110/220V, 60Hz |
110/220V, 50/60Hz |
|||||
Standard Stirring Motor Power |
120W |
||||||
Reaction Vessel Capacity |
1L |
2L |
5L |
10L |
|||
Cooling/Heating Jacket Capacity |
1L |
1.5L |
2L |
3L |
|||
Glass Vessel Temperature Range |
-120℃~250℃ |
||||||
Inner Vessel Pressure |
Under 0.098Mpa |
||||||
Installation Dimension (W*D*H mm) |
440×360×1325 |
440×360×1325 |
520×500×1510 |
700×600×2030 |
|||
Weight(kg) |
40 |
40 |
60 |
90 |
|||
Model |
JGR-20L |
JGR-30L |
JGR-50L |
JGR-80L |
|||
Electrical Requirements |
110/220V, 50/60Hz 1‐PH |
110/220V, 50/60Hz |
|||||
Standard Stirring Motor Power |
120W |
200W |
|||||
Reaction Vessel Capacity |
20L |
30L |
50L |
80L |
|||
Cooling/Heating Jacket Capacity |
6L |
10L |
16L |
24L |
|||
Glass Vessel Temperature Range |
-120℃~250℃ |
||||||
Inner Vessel Pressure |
Under 0.098Mpa |
||||||
Installation Dimension (W*D*H mm) |
720×650×2110 |
750×650×2450 |
750×650×2450 |
850×700×2550 |
|||
Weight(kg) |
110 |
115 |
120 |
140 |
|||
Model |
JGR-100L |
JGR-150L |
JGR-200L |
||
Electrical Requirements |
110/220V, 50/60Hz 1‐PH |
220V, 50/60Hz 1‐PH |
|||
Standard Stirring Motor Power |
120W |
750W |
|||
Reaction Vessel Capacity |
100L |
150L |
200L |
||
Cooling/Heating Jacket Capacity |
30L |
35L |
40L |
||
Glass Vessel Temperature Range |
-120℃~250℃ |
||||
Inner Vessel Pressure |
Under 0.098Mpa |
||||
Installation Dimension (W*D*H mm) |
850×700×2550 |
1000×1300×3000 |
1000×1300×3200 |
||
Weight(kg) |
160 |
210 |
270 |
||
Details
Customer Review
Recommend Products
About Us
FAQ
1.How many ports on the lid?
There are 6 standard ports on the lid of 10L to 200L reactors, including thermometer, vacuum suction, solid inlet, constant pressure funnel, reflux and stirring port. For 1L to 5L reactors, only 5ports on the lid without solid inlet port.
2.Can you provide other type impellers/blades?
Yes, different kinds of blades for your choices, such as pitch blade, anchor blade, sprial propeller blade, ribbon blade, pitch-blade, angled pitch blade, rushton blade, etc.
3.Can I make some changes on this reactor?
No problem, we provide customization service.
4.What’s size of the adapters of the vessel?
They are standard barb or male thread adapters. Please refer to our detailed data specification.
5.Can this reactor make isolate?
Yes, you can use it for isolation by high experienced operators. If you are not familiar with the operation technology, our special designed isolation/crystallization reactor will be your best choice.
