TDP-5 Hot Sale Factory Cheap Price Mini Single Punch Tablet Press Machine for Semi-automatic Series

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Product Description

Descriptive Abstract
This machine is designed for pressing round tablets from various granular materials, applicable to lab used for research and development and to small-scale production. as its feature, it is a small desk-top continuous press driven by motor or man-power. Only one set of punch and die is mounted, the depth of the filling material and the thickness of the tablets can be adjusted.

Technical specifications:

Item	TDP-1.5	TDP-5	TDP-6
Dies	1 Set	1 Set	1 Set
Max. Pressure	15KN	50KN	60KN
Max. Diameter. of Tablet	12mm	Round tablet 18mm, Irregular tablet 20mm	Round tablet 20mm, Irregular tablet 25mm
Max. Depth of Filling	11mm	18mm	17mm
Max.Thickness of Tablet	6mm	7mm	7.5 mm
Production Capacity	5000 tablets/H	4500 tablets/H	3000 tablets/H
Motor	550W/220V	750W/220V	1.1-1.5kw/220V
Machine Size	570450625mm	650440650mm	750380695mm
Net Weight	90kg	120kg	165kg

Some samples

Packaging & Shipping

1.Nomally shipping steps:

2.Our packing and shipping:

Our customer

Certifications
