100L SS 304 steel vacuum emulsifier Machine Production Line /Cosmetic Mixing Tank Equipment/chemical Vacuum emulsifyier
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Planetary food mixer / Double planetary mixer / Vacuum planetary mixer
-
Size 000 00 0 1 2 3 4 5 hard vacant gelatin vegetable hpmc empty capsule
-
Natural Hypromellose seaweed polysaccharide vegan gastrolysis empty capsule
-
Size 00 0 1 2 3 4 Organic Gelatin Vegetable Empty Capsules
-
Empty Gelatin Capsules or HPMC Capsules Size 00 0 1 2 3 4 5 price
-
Empty Vegetarian Pill Capsules Shells
Product Description
Specification
model | SNZ-100 |
Homogenizer power | 1.1 KW |
Homogenizer speed | 0-2850 rpm |
Capacity | 30-100 L |
Design volume | 126 L |
Mainly structure | emulsifying pot, vacuum system, electronic control system |
Stirring mode | frame wall scraping two-way stirring |
stirring power | 1.1 KW |
Stirring speed | 0-86 rpm |
Sealing process | skeleton oil seal |
Inner contact material | stainless steel 304, wall thickness 8 mm, head 8 mm |
Sandwich material | stainless steel 304 material, wall thickness 3 mm |
Outer material | stainless steel 304, wall thickness 3 mm |
Insulation material | aluminum silicate |
Feed mode | vacuum suction or direct feeding |
Discharge mode | bottom discharge |
Spare Parts | Electronic Control Box and Feed pipe |
security system | provided |
Product Description
Vacuum emulsifying machine is an ideal option to produce high-grade skin care products, pharmacy ointment, and many other kinds of creams which needs to be very soft and smooth. It has the functions of heating, mixing, scraping and rotating at different speeds with vacuum supply. It has a very wide application from cosmetics (skin cream, hair gel, lotion etc) and food (jam, chocolate, sauces etc) to pharmacy (ointment, syrup, paste) and chemicals(painting, adhesives, detergents).
Details Images
The machine is mainly made up of oil tank, water tank, vacuum homogeneous tank (main tank), heating system, mixing system, vacuum system, electric lifting system, operation control cabinet and piping system.
Technical parameters
power supply | 380 V 50 HZ 3 phase 5 line |
Total power | 10.5 KW |
Weight | 800 KW |
Installation debugging | Customer Site (380 V Power, Water, Raw Material) |
Random consumables | Remove tools, oil seals, seals |
Service life | Over 10 years |
Advantages & Selling Points
The pot body has 3 layers with heating function, insulation layer and cooling. With the bottom stainless steel φ50mm ball valve (or butterfly valve) to discharge material. 360 degree rotary cleaning ball can clean the body. It has safety protection system like homogenizing overload, overheating etc,. It has equipment jacket over pressure automatic pressure relief device. It can relief the pressure when the jacket pressure is too high. It equipped with indicator lamp with alarm function. When the machine short circuits and low voltage it can emergency stop with the stop button.
Company Profile
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical and chemical machinery and equipment in China. We belong to SINOPEC International Group.
We have a well-experienced team to manufacture pharmaceutical machinery and equipment and a professional design institute. With rich experience in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipment in many varieties. Our main products are glass-lined reactors, fermentors, centrifuges, granulators, mixers, dryers, pulverizers, tablet presses, soft and hard blister packing machines, capsule filling machines, cartoners and rollers.
In the past years, we have made great achievements due to our good credit and service. We have established long-term business relations with many customers and some of our overseas customers have appointed us to be their purchase agency in China. Our products are exported to many countries & areas, such as Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria, the USA, Australia, Canada, Argentina and Chile. Besides machinery and equipment, we also supply production lines, turn key projects and know-how.
In SINOPED you can get your desired goods with the best prices and good quality. We welcome your enquiries from at home and abroad.
Packing & Delivery
FAQ
1. who are we?
We are based in Liaoning, China, start from 2005,sell to Domestic Market(41.00%),North America(13.00%),Mid East(8.00%),South Asia(7.00%),Southeast Asia(6.00%),Eastern Europe(5.00%),Oceania(4.00%),Africa(3.00%),Eastern Asia(3.00%),Southern Europe(3.00%),South America(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Pharmaceutical Machinery
4. why should you buy from us not from other suppliers?
By the honesty, company strength and good quality, Liaoyang SINO harmaceutical Equipment Development Co., Ltd is recognized in the pharmaceutical lines. Our goal is "Exist by quality, and develop by benefit".
5. what services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF;
Accepted Payment Currency:USD,EUR,GBP;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Japanese,Arabic,Russian,Korean
We are based in Liaoning, China, start from 2005,sell to Domestic Market(41.00%),North America(13.00%),Mid East(8.00%),South Asia(7.00%),Southeast Asia(6.00%),Eastern Europe(5.00%),Oceania(4.00%),Africa(3.00%),Eastern Asia(3.00%),Southern Europe(3.00%),South America(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Pharmaceutical Machinery
4. why should you buy from us not from other suppliers?
By the honesty, company strength and good quality, Liaoyang SINO harmaceutical Equipment Development Co., Ltd is recognized in the pharmaceutical lines. Our goal is "Exist by quality, and develop by benefit".
5. what services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF;
Accepted Payment Currency:USD,EUR,GBP;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Japanese,Arabic,Russian,Korean
