Chinese Supplier Plastic Injection Molding Machine Price
- T/T Credit Card

You May Like
-


Injection Mold Machine for Plastic Chair
 -


Good Price SZ-1600A Plastic Hanger Making Machine
 -


Durable High Speed Servo Plastic Bucket/Crate Making Machine
 -


High Capacity Plastic Fork Knife Spoon Cup Making Machine
 -


Plastic Bucket Manufacturing Machines
 -


Full Automatic Plastic Crate Injection Molding Machine

Product Description
High quality and innovative products ,outstanding productivity ,efficient management ,perfect technical solutions and service.
All our machines with CE/TUV approved!!!
|
 Technical Parameter  |
||||
|
 Item  |
 Unit  |
 Parameter  |
||
|
 INJECTION UNIT  |

  |

  |
||
|
 screw diameter  |
 mm  |
 60  |
 65  |
 70  |
|
 screw L/D ratio  |
 L/D  |
 22.7  |
 21  |
 19.5  |
|
 theoretical shot volume  |
 cm*3  |
 848  |
 995  |
 1154  |
|
 shot weight(ps)  |
 g  |
 772  |
 905  |
 1050  |
|
 injection pressure  |
 Mpa  |
 207  |
 176  |
 152  |
|
 theoretical injection rate(ps)  |
 g/s  |
 241  |
 283  |
 328  |
|
 plastic capacity  |
 g/s  |
 35.2  |
 43.3  |
 51.8  |
|
 CLAMPING UNIT  |

  |

  |
||
|
 max.clamping force  |
 KN  |
 3000  |
||
|
 max.opening stroke  |
 mm  |
 590  |
||
|
 space between tie bars  |
 mm  |
 610x610  |
||
|
 mould height  |
 mm  |
 220-630  |
||
|
 max.daylight  |
 mm  |
 1220  |
||
|
 OTHER  |

  |

  |
||
|
 pump motor power  |
 KW  |
 30  |
||
|
 pump pressure  |
 Mpa  |
 16  |
||
|
 heating power  |
 KW  |
 22  |
||
|
 size  |
 m  |
 6.7x1.75x2.25  |
||
|
 net weight  |
 t  |
 11  |
||
|
 oil tank capacity  |
 L  |
 560  |
||
