100% Shut-off Safety Flip-Flap Petal Valve Marine Breakaway Valve Couplings
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
1998
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manufacturer 16 Bar Hose/tank 150# Flange Stainless Steel AISI316TI Marine Breakaway CouplingNegotiableMOQ: 1 -
Marine Hose/pipes Quick Connect Flip-flap Valve Marine Fuel Breakaway CouplingNegotiableMOQ: 1
-
Petal Valve Stainless Steel 4\" 316SS LPG Marine Breakaway Couplings With Flanged ANSI/DIN/JISNegotiableMOQ: 1
-
2021 Factory Price Wholesale High Quality 4 Drum Spill Containment Pallet With Drain CoverNegotiableMOQ: 1
-
Factory Price Wholesale 2 Drum Spill Containment Pallet With Drain EPA 40 CFR 264.175NegotiableMOQ: 1
Marine Breakaway Coupling
Hongruntong Marine Breakaway Coupling, suitable for bottom loading and unloading trucks with inflammable and explosive media. Prevent trucks, rail cars, and ships from accidentally driving away when the loading arms are not separated and causing leakage accidents. At the same time, it prevents damage to the equipment of the vehicle, ship and loading arm, so that when the marine breakaway coupling is unexpectedly pulled by external force, disconnect the loading arm from the vehicle, and make the media at both ends be blocked by the marine breakaway coupling. Leak out. And it's easy to recover afterwards.
Marine Breakaway Coupling: Suitable for use when loading and unloading fluids on ocean and river trough ships.
Product Description
Specification
Model
Laying
|
Nominal Diameter |
Rate of
Flow
|
Flange
Standard
|
Structural Style |
Applicable Medium |
|||||
HM-MB125 |
DN125 |
320 m³/h |
HG/T20592-2009
HG/T20615-2009
|
_ |
Liquid nitrogen, liquid oxygen, LNG, CNG, LPG, liquid ammonia, ethylene, carbon dioxide, liquid chlorine, liquid argon, gasoline, diesel, benzene, methane, methanol, crude oil, etc. |
|||||
HM-MB150 |
DN150 |
500 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
HM-MB200 |
DN200 |
800 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
HM-MB250 |
DN250 |
1300 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
HM-MB300 |
DN300 |
2000 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
HM-MB350 |
DN350 |
2600 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
HM-MB400 |
DN400 |
3200 m³/h |
HG/T20592-2009
HG/T20615-2009
|
Flap |
||||||
*Note: Working Pressure: 4.0mPa, Sealing Material: PTFE, Temperature Range: -196°C to +250°C,
Body Material: SS304-SS316L, Opening Mode: Pulling-rope, breakaway bolt.
|
||||||||||
