High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff

Hongruntong Marine (Beijing) Co., Ltd
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff thumbnail-1
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff thumbnail-2
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff thumbnail-3
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff thumbnail-4
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff thumbnail-5
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff photo-1
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff photo-2
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff photo-3
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff photo-4
High Strength Safe Transfer Fuel 316L Stainless Steel Marine Flexible Quick Pipe Couplings With 100% Shutoff photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2006
Annual Export Value:
US$10 Million - US$50 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Marine Breakaway Coupling

Hongruntong Marine Breakaway Coupling, suitable for bottom loading and unloading trucks with inflammable and explosive media. Prevent trucks, rail cars, and ships from accidentally driving away when the loading arms are not separated and causing leakage accidents. At the same time, it prevents damage to the equipment of the vehicle, ship and loading arm, so that when the marine breakaway coupling is unexpectedly pulled by external force, disconnect the loading arm from the vehicle, and make the media at both ends be blocked by the marine breakaway coupling. Leak out. And it's easy to recover afterwards. Marine Breakaway Coupling: Suitable for use when loading and unloading fluids on ocean and river trough ships.
Product Description
Specification
Model
Laying
Nominal Diameter
Rate of
Flow
Flange
Standard
Structural Style
Applicable Medium
HM-MB125
DN125
320 m³/h
HG/T20592-2009
HG/T20615-2009
_
Liquid nitrogen, liquid oxygen, LNG, CNG, LPG, liquid ammonia, ethylene, carbon dioxide, liquid chlorine, liquid argon, gasoline,
diesel, benzene, methane, methanol, crude oil, etc.
HM-MB150
DN150
500 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
HM-MB200
DN200
800 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
HM-MB250
DN250
1300 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
HM-MB300
DN300
2000 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
HM-MB350
DN350
2600 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
HM-MB400
DN400
3200 m³/h
HG/T20592-2009
HG/T20615-2009
Flap
*Note: Working Pressure: 4.0mPa,   Sealing Material: PTFE,   Temperature Range: -196°C to +250°C,
             Body Material: SS304-SS316L,   Opening  Mode: Pulling-rope, breakaway bolt.
