Hole Shape Square
Wire Gauge 1.8-2.5mm, ( inner wire ), 1.8-3.5mm
Wire diameter 3mm-7mm
Height 80cm-2m
Mesh size(mm) 50X100, 50X150, 50X200
Surface electro galvanized, hot dipped galvanized.
Features:
Field fences have innovative and firm structure, flat surface, uniform opening and good integration. This product offers good flexibility; good pressure resistance, corrosion resistance and weather resistance properties and can serve for a very long time. Even the cut pieces will not deform under pressure. It has excellent corrosion resistance and anti-oxidizing property. Unlike the welded wire mesh fences with the welding spots getting easily broken, our grassland fences are firm forever once installed and make the best materials for protecting grassland, forestry, highway and environments.
SPECIFICATION
| NO. | Specification | Gross Weight ( kg) | Set and bottom wire Dia.(mm) | In wire Dia. (mm) | Volume dia. (mm) |
||
| Type | Specification | ||||||
| 1 | 7/150/813/50 | 102+114+127+140+152+178 | 20.8 | 2.5 | 2 | 280 | |
| 2 | 8/150/813/50 | 89(75)+89+102+114+127+140+178 | 21.6 | 2.5 | 2 | 280 | |
| 3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 22.6 | 2.5 | 2 | 280 | |
| 4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 23.6 | 2.5 | 2 | 280 | |
| 5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.9 | 2.5 | 2 | 280 | |
| 6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 26 | 2.5 | 2 | 280 | |
| 7 | 9/150/1245/50 | 102+114+127+140+140+152+178+203+229 | 27.3 | 2.5 | 2 | 280 | |
| 8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 28.4 | 2.5 | 2 | 280 | |
| 9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 30.8 | 2.5 | 2 | 280 | |
| 10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 19.3 | 2.5 | 2 | 280 | |
| Type | Roll height | Number of | Distance between |
Wire Ø | Roll length |
| (cm) | horizontal wires | vertical wires (cm) | (mm) | (m) | |
| 1960-6-15 | 60 | 6 | 15 |
1.9-3.5 | 50/100 |
| 1960-6-15 | 80 | 6 | 15 | 1.9-3.5 | 50/100 |
| 1980-8-15 | 80 | 8 |
15 | 1.9-3.5 | 50/100 |
| 1995-9-15 | 95 | 9 | 15 | 1.9-3.5 | 50/100 |
| 100/8/15 | 100 | 8 | 15 | 1.9-3.5 | 50/100 |
| 100/16/15 | 100 | 16 |
15 | 1.9-3.5 | 50/100 |
| 120/15/15 | 120 | 15 | 15 | 1.9-3.5 | 50/100 |
| 130/11/15 | 130 | 11 | 15 | 1.9-3.5 | 50/100 |
| 130/18/15 | 130 | 18 |
15 | 1.9-3.5 | 50/100 |
| 149/19/15 | 149 | 19 | 15 | 1.9-3.5 | 50/100 |
| 200/22/15 | 200 | 22 | 15 | 1.9-3.5 | 50/100 |
| - High tensile strength at a smaller wire diameter. | |||||
| - Low weight ,longer service life High strength and rigidity Stable and flexible. | |||||
| - Ideal for pasture fencing in agriculture and animal husbandry. | |||||
APPLICATION
High Tensile Field Fences are made to with stand the hardness of the grassland climate,which are made of graduated steel wire mesh knotted by special machines popularly used in fields and grassland for breeding of deer, cattle and other animals. Our fence products enjoy innovative design, firm structure, flat surface, uniform opening, good flexibility and long service life. The steel wire used in producing field fence offers high strength against the violent clashing of horses and other animals to ensure the safety. The zinc coating layer adds corrosion and rust resistance for the fences.
