Home > Products > wires&cables > 0.05*3.0mm CCA CCS Ribbon Flat Strip for Wire Connector (PIN)
0.05*3.0mm CCA CCS Ribbon Flat Strip for Wire Connector (PIN)
- Ningbo
- T/T L/C
You May Like
-
0.06*1.0mm CCA CCS Flat Wire for Shielding Wire for High-frequency Cable
-
0.06*1.2mm Oscillate CCA Flat Wire for Shielding Wire for High-frequency Cable
-
0.06*1.4mm CCA Ribbon Flat Wire for Shielding Wire for High-frequency Cable
-
0.06*1.6mm CCS Flat Strip for Fuse Wire or Fusible Conductor for Safety Fuses
-
0.06*1.8mm CCS CCA Flat Strip for Fuse Wire or Fusible Conductor for Safety Fuses
-
0.06*2.0mm CCS CCA Ribbon Flat Strip for Photovoltaic Cable
Product Details
| Brand Name | general clad | Place of Origin | China |
Product Description
Base material copper:
· In accordance with EU-standard: DIN EN 13602 (Cu-ETP, Cu-ETP1, Cu-Of, Cu-Of1)
· In accordance with US-standard: ASTM B 224 - 80
· Available in different strength classes according to DIN EN 13599
Optional coating on the base material:
· Tin (Sn),
· Silver (Ag),
· Nickel (Ni)，
· and others on request
Dimensions:
· Thickness from 0.017 to 1.200 mm
· Width from 0.200 to 24.000 mm*
· *> 6.000 mm width made of cut strip, re-rolled
Designs:
· Additional application-optimized strengths to your specifications available
· Edge shape: Milled round, cut
Features:
· Geometrical and mechanical values are reviewed and documented according to your requirements
· Tightest tolerances in terms of thickness and width
· Resistance measurement to defined specifications
· Manufactured to your customized specifications
Applications:
· Fuse wire or fusible conductor for safety fuses
· Welding wire
· Connecting wire
· Wire connector (PIN)
· Shielding wire for high-frequency cable (HF cable)
