China diesel fuel injector test bench CRS-200C
like common rail injector tester EPS205
CRS-200C Common Rail Injector Tester
>>>CHARACTERISTIC
1.Main drive adopts the speed change by frequency change.
2.Controlled by industrial computer in real time.
3.Oil quantity is measured by flowmeter sensor and displayed on 19 LCD.
4.Rail pressure can be tested in real time and controlled automatically, it adopts closed-loop control system
5.Data can be searched, saved and printed (optional).
6.Pulse width of the injector drive signal can be adjusted.
7.Forced cooling system,it contains more than 600 kinds of injectors data by computer
8.Protection function of short-circuit.
9.Plexiglass protective cover, easy and safe operation.
10.it contains the high-pressure protection function.
>>>FUNCTION
1. Test 4 brands of common rail injector.
2. Test 4 pieces of injector at a time.
3. Test the seal performance of common rail injector.
4. Test the pre-injection oil quantity of common rail injector.
5. Test the max. oil quantity of common rail injector.
6. Test the min. oil quantity of common rail injector.
7. Test the average oil quantity of common rail injector.
8. Test the backflow oil quantity of common rail injector.
9. Clean and repair the problem(caused by pollution) of injector.
>>>TECHNICAL PARAMETER
| Rail pressure: | 0~1800 bar |
| Pulse width: | 0.1~200 ms; |
| Test oil filtered precision: | 5μ |
| Lub.oil pressure: | 0~25Mpa; |
| Rotation speed: | 0~2000RPM |
| Input power: | 380V/50hz/3phase or 220V/60hz/3phase |
| Fuel temperature: | 40±2℃ |
| Oil tank capacity: | 20L |
| Overall dimension(MM): | 1120×800×1560; |
| Weight: | 300KG. |
Taian Sunshine Industry CO.is specialized in the sell of diesel fuel injection systems parts for diesel engines.our main parts are Diesel Common Rail Nozzle, Diesel Common Rail Control Valves of different brands, Diesel Common Rail Sensor, SCV Valve, Common Rail Diesel Repair Kits, High Pressure Common Rail Injectors....Today we have established a professional working team under the spirit of “best quality and service in China”.
Taiansunshine expects to make prosperity together with you.
