530V Spcl15 Series ESD Protection Transient Voltage Suppression Tvs Diode Tvs Array Replace Littelfuse Semtech Vishay Bourns

Xiamen SET Electronics Co., Ltd.

● Very low clamping voltage

● Sharp breakdown voltage

● Low slope resistance

● Bi-directional

● Snapback technology for  superior clamping factor

● Symmetric in leads width for easier soldering during assembly.

● IEC-61000-4-2 ESD 30 kV (Air), 30 kV (Contact)

● ESD protection of data lines in accordance with IEC 61000-4-2

● EFT protection of data lines in accordance with IEC 61000-4-4

● Glass passivated junction

● Halogen-free

● Pb-free E4 means 2^nd level interconnect is Pb-free and the terminal finish material is Silver

● RoHS compliant

Through Hole

Axial

● Communication Equipment

● Security & Protection

● Industrial Control Equipment

● Power Supply

● Automotive Electronics

● New Energy

● Lightning Protection

For product quality, our goal is to be industry-leading. We ensure that the quality of the product meets the expected goals from the following process.

Quality Policy.

Qualified Supplier of Raw Materials.

IQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).

Process, Online Inspection and Testing (Function 100% Test).

IPQC (AQL, Dimension, Function, Visual Inspection).

FQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).

Reliability Test (AQL).

OQC (Packaging, Labeling, Quantity Inspection).

Quality Management System (TUV Approved and issued certificate).

SETsafe | SETfuse

SET

TVS Diodes are used to protect sensitive circuit from high-voltage transients.Their p-n junctions have a larger crosssectional area than those of a normal diode,allowing them to conduct large currents to ground without damage. SETsafe | SETfuse supplies TVS Diodes with peak power ratings from 200 W to 30 kW,and reverse standoff voltages from 5.0 V to 512 V.
