WTL 49SMD R433 433.92MHz SMD Crystal Saw Resonator
- 1000 Piece / Pieces per Month
- yantian
- T/T
- 7 days
-
WTL 3*8mm Tuning Fork Crystal Resonator 12.5pf 20ppm 40khz 40.000khz Tuning Fork Crystal
-
WTL HC-49S Quartz Crystal DIP 4.194304MHz Quartz Crystal Resonator HC-49S
-
WTL HC-49S SMD 13.56MHz Crystal Resonator 30ppm 20pf 13.56mhz 13.560mhz +/-30ppm 13.56MHz SMD Crystal
-
WTL ZTTCV16.00MX 16MHz SMD Ceramic Resonator 16.0MHz
-
WTL HC-49S-SMD 433.92MHz Quartz Crystal Replacement TO-39 Resonator HC49SMD 433.92MHz Quartz Crystal
-
WTL HC49S SMD 16MHz Crystal Resonator
Product Details
| Brand Name: | WTL | Place of Origin: | China | Model Number: | WTL2.03958ZX |
Packaging Details
Package size per batch: 22X22X4 cm Gross weight per batch: 0.400 kg
Product Description
Item | Minimum | Typical | Maximum | Unit | |||
Center Frequency | Absolute Frequency | fc | 433.920 | MHz | |||
Tolerance from 433.920MHz | fc |
±75 |
KHz | ||||
Insertion Loss(min) | IL | 1.8 | 2.4 | dB | |||
Quality Factor | Unloaded Q | QU | 18362 | ||||
50Ω Loaded Q | QL | 2150 | |||||
Temperature Stability | Turnover Temperature | T0 | 25 | 40 | 55 | ℃ | |
Turnover Frequency | f0 | fc | |||||
Frequency Temperature Coefficient | FTC | 0.032 | ppm/℃ | ||||
Frequency Aging | Absolute Value during the First Year | |fA| | ≤10 | ppm/yr | |||
DC Insulation Resistance between Any Two Pins | 1.0 | MΩ | |||||
RF Equivalent RLC Model | Motional Resistance | RM | 13.2 | 18.0 | Ω | ||
Motional Inductance | LM | 89.4 | 110.2 | µH | |||
Motional Capacitance | CM | 1.5 | fF | ||||
Static Capacitance | C0 | 1.45 | 1.75 | 2.05 | pF | ||
Item | Value | Unit | |
DC Voltage | VDC | 10 | V |
Operation Temperature | T | -40 ~ +85 | ℃ |
Storage Temperature | Tstg | -55 ~ +125 | ℃ |
RF Power Dissipation | P | 10 | dBm |
