GDI-408-6C Injector Cleaner & Tester
Features:
1. Adopting the powerful ultrasonic cleaning technology, the equipment offers complete cleaning to the injectors/pump.

2.It offers stable testing pressure and large adjustable range controlled through microcomputer.

3.With the help of microcomputer control and LCD display, the equipment makes possible automatic cleaning, testing injectors and real-time monitoring of the dynamic values.

4.Automatic fuel draining through preset programs for some test items.

5.Adopting humanization design can make the system pressure fast restored to the default values.

6.LCD display to show the operation details.

7.Touch button.
Specifications
Working conditions:
Temperature: -10~+40℃ Relative humidity: ＜85% Intensity of outer magnetic field: ＜400A/mNo naked flame within 2m.
Specifications:

Main unit power supply: □ AC220V~50/60Hz □ AC110V~60Hz Ultrasonic cleaner power: 100W Work pressure: 0-7bar Air inlet: 5bar

Operating ProceduresPreparation1) Remove the injector from the motorcycle engine to check the o-rings inside for damage. If it is be damaged need to replace it. Put the outside of injector in gasoline or detergent, and wipe them with soft cloth after cleaning the outside oil sludge carefully. 2) Check the test liquid level to be sure there are enough test liquid inside tank. Pouring test liquid from the port at the top left side of the unit and watch the liquid level in the fuel level viewer. In most cases, filled the liquid up to 1/2 of the tank capacity. 3) Turn on the power switch on the right of the Cabinet. 4) Pour ultrasonic detergent into the ultrasonic cleaning basin so that the needle valve of the injector is covered by the detergent. 5) Connect the injectors with the right couplers.
Tidy up after operating

Tidy-up should be done after cleaning and testing is completed:
1. Press “Drain” icon to drain the test liquid into fuel tank.
2.Switch off the power and unplug from the socket.
3.Clean the Injector Cleaner & Tester control panel with soft cloth.
4. Drain the test liquid from the tank into a container to avoid volatilization. Store the test liquid in a safe place if it can be used again, or dispose of it in accordance with relevant regulations if it is too dirty.
Operation Select Injector Type
1.The test function can be entered after selecting the type of fuel injection nozzle. 2.Different test joints are required for testing different types of fuel injection nozzles. This equipment only provides basic configuration, more configuration of the connector need to be purchased separately. 3.Due to the difference of internal structure, some types of GDI nozzle cannot be tested temporarily. 4.In addition to cleaning the fuel injection nozzle, ultrasonic device can also clean fuel pump, spark plug, and other small size parts, but pay attention to the selection of appropriate cleaning agent. 5.In order to improve the cleaning and testing effect, please connect compressed air when doing test of GDI nozzle, and set the air pressure at 6-8 bar.


Product Tags: 220V and 110V GDI-408-6C maquina bico injetor gdi inyectores gdi gdi machine , GDI Fuel Injector Cleaner And Tester Compatible For Universal GDI And Benz Injector GDI-408-6C
