Home > Industrial Equipment & Components > Valve > Ball Valve > COVNA DN40 1.5 Inch 3 Way L Port 220V AC Tri Clamp Food Grade 316 Stainless Steel Motor Operated Sanitary Ball Valve
COVNA DN40 1.5 Inch 3 Way L Port 220V AC Tri Clamp Food Grade 316 Stainless Steel Motor Operated Sanitary Ball Valve
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2007
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
COVNA DN50 2 Inch ANSI Class 150 EPDM Rubber Seat Lug Type Cast Steel 12 Volt Modulating Electric Actuator Butterfly ValveNegotiableMOQ: 1 -
COVNA 1/2 Inch 90 Degree 3Way Brass Motorized Electric Mini Ball ValveNegotiableMOQ: 1
-
4 Inch Double Flange Ductile Iron Electric Actuator Butterfly Valve Motorized Butterfly ValveNegotiableMOQ: 1
-
DN15 1/2 Inch 2 Way Full Port 24VDC NPT Threaded 304 Stainless Steel Water Automatic Electric Spring Return Ball ValveNegotiableMOQ: 1
-
Regulating Type Double Union Control PVC Ball Valve With Electric ActuatorNegotiableMOQ: 1
Product Description
COVNA DN40 1.5 inch 3 Way L Port 220V AC Tri Clamp Food Grade 316 Stainless Steel Motor Operated Sanitary Ball Valve
Advantages:
- MOQ: 1 set
- 19 years of valve manufacturing experience
- Strong inventory, part of commission returned for bulk delay
- Product quality will be guaranteed for 1 year
- OEM service to help customers to promote their brands
- Offer various international standard, ANSI, JIS, DIN, etc
- Custom complaints handed by one stop professional service.
- Inquiry will be replied within 8 hours
| Size Range | 1/2"~2", DN15~DN100 |
| Operating Pressure | 1.6MPa |
Products Description
Company Profile
Certification
Exhibition
Cooperation Customers
Finished Project
Packaging & Delivery
FAQ
Q:Which voltage of the electric actuator?
A: DC24V, AC24V, AC110V, AC220V
AC380V can be customized and DC12V is available for some smaller torque of actuator.
Q: What is the actuation time for electric actuator?
A: It depends on the torque of actuator.
The detailed timing would be as the following:
* COVNA-05(50Nm)-20 seconds
* COVNA-10(100Nm)/COVNA-16(160Nm)-25 seconds
* COVNA-30(300Nm)/COVNA-60(600Nm)-60 seconds
* COVNA-125(125Nm)/COVNA-250(2500Nm)/COVNA-400(4000Nm)-100 seconds.
Q: Can the actuation time be faster?
A: Electric actuator can be customized the quick actuation gear,
the soonest actuation time can be reach 10 seconds to open and close.
Q: What type of electric actuator you provide?
A: ON/OFF type, Regulation type and Intelligent type.
Q: What is the difference from ON/OFF type, Regulation type and Intelligent type?
A: 1)ON/OFF type
ON/OFF type is fully open and fully closed.
2)Regulation type
1.With input/output signal:4-20mA or 0-10V;
2.Opening position of valve can be adjusted by signal;
3.Available for PLC system.
3)Intelligent type
1.With input/output signal:4-20mA or 0-10V;
2.Opening position of valve can be adjusted by signal;
3.Available for PLC system.
4.With display screen to acheieve site control.
Q: Can this electric valve be resettable (normally open / closed) automatically when power is removed?
A: Our regular electric actuator can't be resettable automatically while power-off.
But it can go to the multiturn electric actuator model with the extra electrical storage device along,
which acheieve the valves can be automatic reset(normally closed) while power failure.
Q: Have the electric actuator had the presence of limit switches (contact about the position of the cut-off device)?
A: Yes, there is the position indicator on the top of actuator.
The open/closed status can be checked visually.
Q: Which type of protection class of this electric actuator?
A: IP65, IP68, Explosion proof.
Q. Is there any manual override of electric valve?
A: Yes, every electric valve includes the manual override.
You can open/close
Q:Have the electric valve had the limiting operating time?
A: Electric haven't had the limiting operating time.
It can be working for 99 hours continually without getting heating.
