Pepperl Fuchs HiC2822 Switch Amplifier With Good Price In Stock
- 1000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Product Details
Brand Name: | Pepperl Fuchs | Model Number: | HiC2822 |
Product Description
Pepperl fuchs HiC2822 Switch Amplifier With Good Price In Stock
Pepperl + Fuchs HiC2822 2-channel-channel isolated barrier is used for intrinsic safety applications. It transfers digital signals (NAMUR sensors/mechanical contacts) from a hazardous area to a safe area.
Brand: Pepperl + Fuchs
Place of origin: Singapore / Germany
1. General Introduction
Pepperl + Fuchs HiC2821 1-channel isolated barrier for ADV151 is used for intrinsic safety applications. It transfers digital signals (NAMUR sensors/mechanical contacts) from a hazardous area to a safe area.The proximity sensor or switch controls a form a normally open relay contact for the safe area load. The module output changes state when the input signal changes state. The mode of operation can be reversed with switch S1 on the side of the unit. One additional relay is available for the fault output. Line fault detection (LFD) can be selected or disabled via switch S2. During an error condition, the relay reverts to its de-energized state and the LEDs indicate the fault. A separate output bus is available. The fault conditions can be monitored via a Fault Indication Board. This module mounts on a HiC Termination Board.
2. Features
• 1-channel isolated barrier
• 24 V DC supply (bus powered)
• Dry contact or NAMUR inputs
• Usable as signal splitter (1 input and 2 outputs)
• Relay contact output
• Fault relay contact output
• Line fault detection (LFD)
• Up to SIL 2 acc. to IEC 61508
3. General Specification for HiC2822
Technical data | HiC2822 |
Supply | |
Rated voltage | 19 ... 30 V DC via Termination Board |
Ripple | ≤ 10 % |
Rated current | ≤ 30 mA |
Power loss | ≤ 600 mW |
Power consumption | ≤ 600 mW |
Input | |
Rated values | acc. to EN 60947-5-6 (NAMUR |
Open circuit voltage/short-circuit current | approx. 10 V DC/approx. 8 mA |
Switching point/switching hysteresis | 1.2 ... 2.1 mA/approx. 0.2 mA |
Line fault detection | breakage I ≤ 0.1 mA, short-circuit I ≥ 6.5 mA |
Pulse/Pause ratio | ≥ 20 ms/≥ 20 ms |
Output | |
Output I | signal; relay |
Output II | signal; relay |
Contact loading | 50 V DC/0.5 A |
Minimum switch current | 2 mA/24 V DC |
Energized/De-energized delay | ≤ 20 ms/≤ 20 ms |
Mechanical life | 107 switching cycles |
Error message output | |
Output type | open collector transistor (internal fault bus) |
Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
Mechanical specifications | |
Protection degree | IP20 |
Mass | approx. 100 g |
Dimensions | 12.5 x 128 x 106 mm (0.5 x 5.1 x 4.2 in) |
Data for application in connection with Ex-areas | |
EC-Type Examination Certificate | BASEEFA 06 ATEX 0093 X |
Statement of conformity | PF 08 CERT 1047 X |
FM approval | |
Control drawing | 16-534FM-12 (cFMus) |
IECEx approval | IECEx BAS 06.0026X |
Approved for | [Ex ia] IIC, [Ex ia] I |
4. Selection tables
Termination Board & Barrier Module Selection table for Yokogawa CENTUM VP DCS system | ||||||
Yokogawa | Pepperl+Fuchs Termination Board | Pepperl+Fuchs Barrier Module | ||||
CENTUM VP | Channel | Class | Number of module | Type | Channel | Type |
Selection of Digital Input signals | ||||||
ADV151 | 32 | IS | 32 | HiCTB32-YC3-RRB-AK-CC-DX32 | 1 | HiC2821 |
ADV151 | 32 | IS | 36 | HiCTB16-YC3-RRB-AK-CC-DX32 | 2 | HiC2822 |
ADV151 | 32+ | IS | 40 | HiCTB08-YC3-RRB-AK-CC-DX32 | 4 | HiC2824 |
Selection of Digital Output signals | ||||||
ADV551 | 32 | IS | 32 | HiCTB32-YC3-RRB-AK-CC-DX32-Y1 | 1 | HiC2871 |
ADV551 | 32 | IS | 16 | HiCTB16-YC3-RRB-AK-CC-DX32 | 2 | HiD2872 HiD2876 |
Selection of Analog Input signals | ||||||
AAl143 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC-Al16 | 1 | HiC2025 |
AAl143 | 16 | IS | 8 | HiDTB08-YC3-RRB-KS-CC- Al16 | 2 | HiD2026 HiD2030 HiD2082 |
AAl143 | 16 | IS | 16 | HiCTB08-YC3-RRB-AK-CC- Al16 | 1 | HiD2081 |
AAl141 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC- Al16-Y1 | 1 | HiC2025 |
AAl141 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC- Al16-Y2 | 1 | HiC2025 |
AAl141 | 16 | IS | 8 | HiDTB08-YC3-RRB-KS-CC- Al16-Y1 | 2 | HiD2026 HiD2030 |
Selection of Analog Output signals | ||||||
AA1543 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC-AO16 | 1 | HiC2031 |
AA1543 | 16 | IS | 8 | HiCTB16-YC3-RRB-KS-CC-AO16 | 2 | Hid2038Y |
ADV151 | 32+ | IS | 40 | HiCTB08-YC3-RRB-AK-CC-DX32 | 4 | HiC2824 |
Selection of Analog Input and Output signals | ||||||
AAI841 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC-AM16 | 1 | HiC2025 HiC2031 |
AAI841 | 16 | IS | 8 | HiDTB08-YC3-RRB-KS-CC-AM16-Y1 | 2 | HiD2026 HiD2030 HiD2032 |
AAI135 AAI835 | 8 | IS | 8 | HiCTB08-YC3-RRB-KS-CC-AM08 | 1 | HiC2025 HiC2031 |
AAI841 | 16 | IS | 16 | HiCTB16-YC3-RRB-KS-CC-AM16-Y1 | 1 | HiC2025 HiC2031 |
AAI841 | 16 | IS | 8 | HiDTB08-YC3-RRB-KS-CC-AM16 | 2 | HiD2026 HiD2038Y |
5. Diagrams
HID2025 | HID2038 | HiC2842 |
HID2026 | HID2024 | HiC2851 |
HID2061 | HID2096 | HiC2853 |
HID2062 | HID2025SK | HiC2853R1 |
HID2071 | HID2026SK | HiC2853R2 |
HID2072 | HIC2095 | HiC2831R3 |
HID2033 | HIC2065 | HiC2832 |
HID2034 | HIC2027 | HiC2832R2 |
HID2031 | HIC2068 | HiC2832R3 |
HID2032 | HIC2077 | HiD2822 |
HID2037 | HIC2000 | HiC2025Y1 |
HID2029 | HIC2025ES | HiC2000 Blank |
HID2030 | HIC2031HC | HiD2000 Blank |
HID2029SK | HIC2025HC | HiC2877 |
HID2030SK | HID2025ES | HiD2876 |
HID2035 | HIC2027DE | HiC2871 |
HID2036 | HID2081 | HiC2873 |
HID2000 | HID2082 | HiC2873Y1 |
HID2038Y | H-CJC-SP-8 | HiC5861 |
HID2012 | H-CJC-SC-8 | HiC5861Y1 |
HiC2441 | HIC2077-Y1 | HiC5863 |
HiC2821 | HIC2441 | HiC5863Y1 |
HiC2822 | H-CJC-PT100 | HiC2025A |
HiD2824 | HIC2025 | HiD2022 |
HiD2844 | HIC2031 | HiD2022SK |
HiC2831 | HIC2081 | HiC2027ES |
HiC2831R1 | HiD2842 | HiC2832R1 |
HiC2831R2 | HiC2871A | HiC2841 |
HiD2872 | HiC2883 |
\
