Hydraulic Pump and Motor Test Stand,Digital Hydraulic Motor Test Stand

Name: Hydraulic Pump and Motor Test Stand,Digital Hydraulic Motor Test Stand
Brand: Yuanyi
SKU: 169643765
Availability: InStock

Jinan Yuanyi Hydraulic Equipments Co.,Ltd

US$ 20000 - 25000 MOQ: 1 Set

Key Specifications

Brand Name:

Yuanyi

Place of Origin:

China

Model Number:

YY-90

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

20 days

Brand Name Yuanyi

Place of Origin China

Model Number YY-90

Power Hydraulic

Usage Other, pump repairing

Hydraulic Pump and Motor Test Stand,Digital Hydraulic Motor Test Stand

Computerized Hydraulic Pump and Motor Test Bench, Hydraulic Piston Motor Testing Equipment

Product Name	Hydraulic Pump Test Bench
Function	Suitable for the hydraulic maintenance and testing of construction machinery, industrial and marine equipment etc.
Test Projects	1)No-load Running and Testing. 2)Displacement Experiment. 3)Power (Volume) Test. 4)Pressure Pendulum Test. 5)Leakage Test. 6)Variable Characteristic Test.
Performance Parameters	Appliance Standards	JB/T7039-2006, JB/T7041-2006, JB/T7043-2006
	Power Range	75KW, 90KW, 110KW, 160KW Custom
	Pressure Setting Range	0~35MPa
	Range of Flow	0~400L/min
	Range of Speed	0~2000r/min
	Speed Control	Bi-directional Frequency Control.
	Control Method	Manual or Computer Control.
	Temperature Control	Heating & Cooling ( water cooling or air cooling is optional).
Composition of The Structure	Dynamic system, the hydraulic control system, the hydraulic oil filter temperature control system, the electrical control system, the data acquisition test system.
