As the top reliable LED display manufacturer, LEDFUL has 3~5 years warranty on outdoor advertising LED display screen. We offer high quality LED stage screens for sale for customers’ different requirements.
LI2.6 | LI2.8 | LI2.9 | LI3.9 | LI4.8 | LI5.9 | LI6.2 LO3.9 | LO4.8 | LO5.9 | LO6.2
· Front Maintenance
· Curved Installation
· No Light Leakage
· Light and Thin
Parameter
L Series Outdoor |
LO 3.9 |
LO 4.8 |
LO 5.9 |
LO 6.2 |
Pixel Pitch(mm) |
3.91mm |
4.81mm |
5.95mm |
6.25mm |
Pixel Matrix Per Sq.m |
65536 |
43264 |
28224 |
25600 |
Pixel Configuration |
SMD1921 |
SMD2727 |
SMD3535 |
SMD3535 |
Brightness (nits) |
≥4000 |
≥4500 |
≥4500 |
≥4000 |
Scan |
1/16 |
1/13 |
1/7 |
1/10 |
Cabinet Resolution |
128×128 |
104×104 |
84×84 |
80×80 |
Power Con. (Max / Avg) |
800/250w/sq.m |
780/250w/sq.m |
820/260w/sq.m |
800/250w/sq.m |
Module Dimension |
250x250mm / 0.82x0.82feet |
|||
Cabinet Dimension |
500x500x80mm / 1.64x1.64x0.26feet |
|||
Cabinet Weight |
8kg / 17.6Ib ( Die-casting Aluminum) |
|||
Service Access |
Front / Rear |
|||
Rotation Angle |
-10° and +10° |
|||
Refresh Rate (HZ) |
1920 |
|||
Grey Scale (bit) |
16 |
|||
Viewing Angle (H/V) |
160 / 160 |
|||
IP Rate |
IP65 |
|||
Input Voltage (AC) |
110 / 240 |
|||
L Series Indoor |
LI 2.6 |
LI 2.8 |
LI 2.9 |
LI 3.9 |
LI 4.8 |
LI 5.9 |
LI 6.2 |
Pixel Pitch(mm) |
2.604mm |
2.84mm |
2.976mm |
3.91mm |
4.81mm |
5.95mm |
6.25mm |
Pixel Matrix Per Sq.m |
147456 |
123904 |
112896 |
65536 |
43264 |
28224 |
25600 |
Pixel Configuration |
SMD2121/SMD1515 |
SMD2121 |
SMD2121 |
SMD2121 |
SMD2121 |
SMD3528 |
SMD3528 |
Scan |
1/32 |
1/22 |
1/28 |
1/16 |
1/13 |
1/7 |
1/10 |
Cabinet Resolution |
192×192 |
176×176 |
168×168 |
128×128 |
104×104 |
84×84 |
80×80 |
Power Con. (Max/Avg) |
800/250w/sq.m |
780/240w/sq.m |
760/220w/sq.m |
700/200w/sq.m |
720/200w/sq.m |
740/220w/sq.m |
700/200w/sq.m |
Module Dimension |
250x250mm / 0.82x0.82feet |
||||||
Cabinet Dimension |
500x500x80mm / 1.64x1.64x0.26feet |
||||||
Cabinet Weight |
8kg / 17.6Ib (( Die-casting Aluminum) |
||||||
Service Access |
Front / Rear |
||||||
Rotation Angle |
-10° and +10° |
||||||
Brightness (nits) |
≥1000 |
||||||
Refresh Rate (HZ) |
3840 |
||||||
Grey Scale (bit) |
16 |
||||||
Viewing Angle (H/V) |
160 / 160 |
||||||
IP Rate |
IP31 |
||||||
Input Voltage (AC) |
110 / 240 |
||||||
Specifications and photos are subject to change without prior notice.
Front Maintenance
The magnet LED modules can be dismantled by tools on front side.
Curved Installation
Curved with every 2.5° between -10°and 10°, which can make convex and concave.
Work with E Series
L series and E series can be installed together for various installation.
Ultra Fast Response
The response speed exceeds the response limit of the naked eyes, while playing the high speed dynamic images in an LED Screen, it will have more advantages, there will be no ghosting&twisting and it will perfectly provide the dynamic images.
No light leakage trouble
No light leakage design with specific strips on side of cabinet and behind neighbour module.
Wide Viewing Angle
Both 160° from horizontal & vertical for the viewing angle.
Seeing from five directions, it would be still the natural and clear image in an LED display.
Faster & Easier Installation
Hanging or stacking, L series with light and thin features makes installation faster and easier.
