OrangeMech Fully Automatic Tube / Cosmetic / Soap / Bottle / Face Mask Carton Box Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2011
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Prices 300m-600m Drilling Depth Hydraulic Water Well Drilling Rig MachineNegotiableMOQ: 1 -
Sauce Paste Peanut Butter Packaging MachineNegotiableMOQ: 1
-
OrangeMech Servo Motor Control Snacks Wrapping Machine Horizontal Biodegradable Candy Packing Machine LineNegotiableMOQ: 1
-
OrangeMech Automatic Cbd Oil Dropper Bottle Horizontal Cartoning Folding and Sealing MachineNegotiableMOQ: 1
-
OrangeMech Factory Price Ice Cream Cone Making Machine Flower Ice Cream Cone Processing SolutionNegotiableMOQ: 1
Product Description
high speed horizontal cartoning machine food box carton packing machine price
high speed horizontal cartoning machine food box carton packing machine price
Automatic Boxing Packing Machine is automatic high speed continuous cartoning machine which is high performance product incorporates pneumatic, photo, electric, mechanic in one. It suitable for automatic inserting ALU-PVC blister, bottle, soft tube, soft AL/AL strips and pouch into carton, also can link to matching machine to form production line.
Technical Parameters:
Power supply |
380V 50Hz |
Power (Power KW) |
1.5KW |
Production speed (Speed) |
about 20-70 boxes / minute |
Box size |
L（70-280）mm×W（80-180）mm×H（20-115）mm |
Product height |
Less than 150mm |
Air source |
0.5-0.8 Mpa |
Air consumption |
120-160L/min |
Machine size |
4000mm×1280mm×1900mm |
Weight |
about 1.4T |
Features:
1.The whole machine can be designed and manufactured according to the current GMP standard workshop space.
2.Separate design of each functional area of the whole machine, using imported photoelectric eye tracking, automatic detection and automatic control of mechanical operation
3.Photoelectric detection of the product can realize automatic boxing and sealing.
4. The movement of each station of the whole machine has extremely high electronic automatic synchronization, which makes the operation of the machine more coordinated, more balanced, and low noise.
5. This cartoning machine is easy to operate. PLC programmable control, touch-type man-machine interface.
6. The machine's PLC automation control system output interface can realize real-time monitoring of downstream packaging equipment.
7. High degree of automation, wide control range, high control precision, sensitive control response and good stability.
8. The number of parts is small, the structure of the machine is simple, and the maintenance is convenient.
9. This machine is designed with low decibels (equipment working noise W75 decibels).
10. The maximum production speed of this line is 50 boxes/min, and the stable production speed is: 30-50 boxes/min.
11. The foot of the whole line adopts a threaded foot plate, which is adjustable in height.
Application:
automatic cartoning machine suitable for pharmaceuticals, food, household chemicals, hardware and electrical industries for the packaging of blisters, bottles, vials, pillow packs, toothpaste, ect. It can fold leaflets, open cartons, insert the products and leaflets into cartons, emboss, tuck-in or hot-melt closures and automatically discharge cartons.
Related Products
Packing&Shipping
1.We can load container at: Qingdao,shanghai, Ningbo, Tianjin, Guangzhou etc. 2.Orange provide shipping method:Courier service,Air transport,Sea Transport
3.Can accept order: Full container cargo load,Less container load
4.Our service: EXW, FOB,CIF,CNF,Door to Door etc.
3.Can accept order: Full container cargo load,Less container load
4.Our service: EXW, FOB,CIF,CNF,Door to Door etc.
5.We always choose the most economical and reliable shipping company to make sure you receive the goods in time. 6.The tracking number will be provided to you once the consignment is shipped.
After Sales Service
All products purchased in our company are guaranteed to keep in good repair for one year.
If quality problems happen in guarantee period, our company will maintain for free.
a. Before sending the machine, we will test and adjust, so you can use directly when you get it.
b. Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we
will solve your problems in time.
If you are caught in some problems when using our products, welcome to contact us at any time.
a. Any problems occur while using, professional advice will be offered.
b. All kinds of frequently used parts are supplied all the year round.
If quality problems happen in guarantee period, our company will maintain for free.
a. Before sending the machine, we will test and adjust, so you can use directly when you get it.
b. Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we
will solve your problems in time.
If you are caught in some problems when using our products, welcome to contact us at any time.
a. Any problems occur while using, professional advice will be offered.
b. All kinds of frequently used parts are supplied all the year round.
Company Introduction
FAQ
Q1: What are the payment terms?
A: We usually accept payment by T/T, L/C, Western Union or Escrow.
Q2 : Can any of the products be custom imprinted?
A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to customize for you.
Q3: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are alibaba legitimate certification company (VIP), and we support payment terms like L/C, Escrow, to ensure your safety.
Q4: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!
Q5: Where will the orders be shipped from?
A: It will ship from the main ports China. And We will find the shipping company which will offer the best and most economical freight for our customers.
A: We usually accept payment by T/T, L/C, Western Union or Escrow.
Q2 : Can any of the products be custom imprinted?
A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to customize for you.
Q3: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are alibaba legitimate certification company (VIP), and we support payment terms like L/C, Escrow, to ensure your safety.
Q4: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!
Q5: Where will the orders be shipped from?
A: It will ship from the main ports China. And We will find the shipping company which will offer the best and most economical freight for our customers.
