Industrial Shrimp Fish Dehydrated Vegetables Freeze Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2011
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cnc Potato Chips Peas Food Batch Freezer Fast Freezing Machine Mushroom Meat Fish Shrimp Vegetable Quick Freezing EquipmentNegotiableMOQ: 1 -
Small Freezer Iqf Tunnel Fruits Flash Freeze Food Equipment for FruitsNegotiableMOQ: 1
-
Industrial Restaurant Use Commercial Lettuce Cutting Slicer MachineNegotiableMOQ: 1
-
Nitrogen Liquid Industrial Quick Belt Tunnel Freezer Fruit And Vegetable Quick Freezing MachineNegotiableMOQ: 1
-
Industrial Cryogenic Liquid Nitrogen Type Tunnel Quick Freezer For Food Pork Meat SteakNegotiableMOQ: 1
Products show
Industrial shrimp fish dehydrated vegetables freeze machine
Final Products
Features
1. The whole equipment is designed and manufactured in accordance with the requirements of HACCP to ensure food hygiene and safety, so that food processing enterprises can successfully pass the HACCP certification and obtain food export permits.
2. The frame structure is made of stainless steel SUS304, all of which are welded by argon arc welding.
3. The evaporator is made of aluminum tube and aluminum sheet, with large distance structure, so that the defrosting interval is long.
4. Defrosting method: the external water valve is used to control the water uniformly.
5. There is a certain inclination at the bottom of the storage plate, and there is a drainage hole, which is convenient for cleaning and ensures that there is no sanitary dead angle inside the equipment.
6. The whole warehouse is equipped with an access door, which is convenient for cleaning and maintenance in the warehouse.
7. The mesh belt chain transmission mechanism is adopted, and the mechanical failure rate is low. Adopt high-strength chain, sprocket and stainless steel mesh to ensure long life.
8. Set the mesh belt type, mesh size，buckle shape and corresponding channel height according to the type of incoming products to ensure the smooth passage of goods and low ventilation resistance to improve the freezing speed.
Product Parameter
Product |
fish, shrimp, sardines, mackerel, tilapia, etc. |
Placement |
Place on the conveyor belt directly |
Primary temperature |
20℃（central） |
Discharge temperature |
－18℃（central） |
Freezing time |
10-30min, can be adjusted |
Freezing temperature |
-40℃ |
Cooling consumption |
40kW（+35℃/-42℃） |
Freezing capacity |
200kg/h（100kg/h, 300kg/h, 500kg/h, 1000kg/h, 3000kg/h） |
Part |
No. |
Description |
Size |
Material/Brand |
Mechanical |
1 |
Mesh belt |
Stainless steel wire mesh φ1.5mm |
SUS304 |
Rod diameter φ10mm |
SUS304 |
|||
Pitch：50.8mm |
||||
2 |
Mesh belt support structure |
Square tube for main support of mesh belt |
SUS304 |
|
3 |
Transmission part |
Reducer |
BANG FEILI |
|
Precision design drive chain |
SUS304 |
|||
Stamping chain driving part |
SUS304 |
|||
Refrigeration system |
1 |
Evaporator |
Fin thickness0.3mm |
Aluminum |
Evaporating aluminum tubeφ19 |
Aluminum |
|||
2 |
Fun |
Air duct |
SUS304 |
|
Fan blade |
||||
3 |
Windbreak system |
Wind guide plate and wind shield 1.5mm |
SUS304 |
|
1 |
Insulation Chamber board |
The top plate and bottom plate are double stainless steel polyurethane insulation board |
Stainless steel plate with inner and outer thickness of 0.5mm |
|
The side plate is double stainless steel polyurethane insulation board |
Inner 0.5mm, outer 0.8mm stainless steel plate |
|||
120mm thick double stainless steel panel |
Double side SUS304 |
|||
2 |
Door |
Standard distribution heating |
SUS304 |
|
3 |
Air deflector Wind shield |
1.5mm |
SUS304 |
|
Electric control system
|
1 |
Electric control part |
All stainless steel waterproof electric control cabinet |
SUS304 |
Button switch |
Zhejiang |
Factory Real Shot
Company Profile
FAQ
Q1: What are the payment terms?
A: We usually accept payment by T/T, L/C, Western Union or Escrow.
A: We usually accept payment by T/T, L/C, Western Union or Escrow.
Q2 : Can any of the products be custom imprinted?
A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to customize for you.
A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to customize for you.
Q3: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are alibaba legitimate certification company (VIP), and we support payment terms like L/C, Escrow, to ensure your safety.
A: We are alibaba legitimate certification company (VIP), and we support payment terms like L/C, Escrow, to ensure your safety.
Q4: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!
A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!
Q5 : Where will the orders be shipped from?
A: It will ship from the main ports China. And We will find the shipping company which will offer the best and most economical freight for our customers.
A: It will ship from the main ports China. And We will find the shipping company which will offer the best and most economical freight for our customers.
Packing & Delivery
Standard export wooden case package:
1.We can load container at: qingdao,shanghai, ningbo, tianjin, guangzhou etc.
2.Orange provide shipping method:Courier service,Air transport,Sea Transport
3.Can accept order: Full container cargo load,Less container load
4.Our service: EXW, FOB, CIF ,CNF,Door to Door etc.
5.We always choose the most economical and reliable shipping company to make sure you receive the goods in time.
6.The tracking number will be provided to you once the consignment is shipped.
