ZigBee dimmer switch home smart lighting control dimmer switch
Introductions
Main Features
- ZigBee HA1.2 compliant
- Wireless on/off switch
- Wireless dimmer control
- Easy to be installed or adhered anywhere in the house
- Extremely low power consumption
Main Specifications
| Wireless Connectivity | ZigBee 2.4GHz IEEE 802.15.4 |
| RF Characteristics |
Operating frequency: 2.4GHz Internal PCB Antenna Range outdoor/indoor: 100m/30m |
| ZigBee Profile |
Home Automation Profile (optional) ZigBee Lighting Link Profile (optional) |
| Battery |
Type: 2 x AAA batteries Voltage: 3V Battery Life: 1 year |
| Dimensions |
Diameter: 90.2mm Thickness: 26.4mm |
| Weight | 66g |
Multi view
Any home can be SMART if you want,system module in us:
- Energy ( Smart Plug, Din rail, Load Control, Power Clamps)
- Comfort ( HVAC Thermostat, Fan coil thermostat, AC control etc)
- Security ( Door/window sensor, smoke detector, multi-sensors etc)
- Lighting ( LED bulb, Relays, Smart plug, wireless dimmer switch etc)
- Video (IP camera)
Q1. How can I return this device to default factory settings?
A1: Please use a pin key tool to press and hold the reset button for ten seconds (the
LED indicator will flash 3 times in three seconds and flash again 3 times in 10 seconds).
Q2. Can I use this device to control a CCT tunable LED bulb
without a gateway and the mobile app?
A2: Yes. But the LED bulb needs to be based on standard ZigBee Lighting Link profile
such as LED622. If you have a LED622, please use this device and follow the
instructions below.
Note: Before you proceed, please return all the devices to default factory setting.
(1) Place the SLC603 Dimmer Switch near to the LED622, press and hold the reset
button of the SLC603 Dimmer Switch for about three seconds until the LED flashes
green three times.
(2) If pairing is successful, the LED bulb will flash several times.
About Owon
OWON Technology (part of LILLIPUT Group) is an ISO 9001:2015 certified Original
Design Manufacturer specialized in the design and manufacturing of electronic and
computer-related products since 1993.
Backed by a solid foundation in embedded computer and LCD display technology,
and by partnering with major industry players, OWON further integrates IOT
technologies into its technology mix, offering both standardized products and
customized solutions for utilities, cable/broadband operators, home builders,
property management, contractors, and the retail market. OWON’s line of ZigBee
technologies covers Smart Energy, Home Automation, and Light Link.
ISO Certification
ODM/OEM Service
- Transfers your ideas to a tangible device or system
- Delivers full-package service to achieve your business goal
- Full-line technical service including industrial & structural design, hardware & PCB design, firmware & software design, and system integration;
- 20-plus years of manufacturing experience backed by a mature and efficient supply chain;
- Stable and consistent human resources as well as active employee involvement;
- The combination of “international presentation” and “made in China” guarantees high-level customer satisfaction without sacrificing cost effectiveness.
