Primary technical parameters:
Capacity: 1,000-100,000 m3.
Type: Aboveground, flat bottom, cylindrical, bimetal, atmospheric.
For content: Liquefied natural gas (LNG), liquefied ethane (LC2H6), liquefied ethylene (LC2H4)...
Design temperature: -196~50 ℃.
Design pressure: 10-50 kPa.
Materials: Stainless steel (16MnDR/S30408) for inner tank, Stainless steel for Outer tank;
Codes & standards: ASME BPV Section VIII, Division 1; API 620-2013; GB/T 26978-2011.
Insulation method: TCP (thermal corner protection), Expanded perlite, foamglass blocks, dry nitrogen etc.
Features:
• One-stop solution, customized configuration for cost-effectiveness.
• State-of-the-art technology, improvement to details.
• Trust built on quality, well-received by hundreds of customers.
• Worry-free maintenance, timely on-line support.
Please contact us for more details, thank you!
