Product Description
GJYXFCH FTTH Fiber Optic Cable 1 2 4 Core Single Mode Outdoor FTTH fiber optic cable Drop Wire
Product description/ PRODUCT
The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP/KFRP/STEEL) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or colored LSZH sheath.
Characteristics/ PRODUCT
· Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber;
· Single steel wire or messenger as the additional strength member ensures good performance of tensile strength;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and maintenance;
· Low smoke, zero halogen and flame retardant sheath.
Optical Characteristics/ PRODUCT
|
G.657 |
50/125μm |
62.5/125μm |
||
Attenuation |
@850nm |
|
|
≤3.5 dB/km |
≤3.5 dB/km |
@1300nm |
|
|
≤1.5 dB/km |
≤1.5 dB/km |
|
@1310nm |
≤0.40 dB/km |
≤0.40 dB/km |
|
|
|
@1550nm |
≤0.30 dB/km |
≤0.30dB/km |
|
|
|
Bandwidth (Class A) |
@850nm |
|
|
≥500 MHz·km |
≥200 MHz·km |
@1300nm |
|
|
≥500 MHz·km |
≥500 MHz·km |
|
Numerical Aperture |
|
|
0.200±0.015NA |
0.275±0.015NA |
|
Cable Cut-off Wavelength |
≤1260nm |
≤1260nm |
|
|
Technical Parameters/ PRODUCT
Fiber count |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long /Short Term N |
Crush Resistance Long /Short Term N/100mm |
Bending Radius Static /Dynamic mm |
1 |
(2.0±0.)×(5.0±0.2) |
20 |
300/600 |
1000/2200 |
20/40 |
2 |
(2.0±0.2)×(5.0±0.2) |
20 |
300/600 |
1000/2200 |
20/40 |
4 |
(2.0±0.2)×(5.0±0.2) |
20 |
300/600 |
1000/2200 |
20/40 |
6 |
(2.5±0.2)×(6.0±0.2) |
24 |
300/600 |
1000/2200 |
20/40 |
8 |
(2.5±0.2)×(6.0±0.2) |
24 |
300/600 |
1000/2200 |
20/40 |
12 |
(2.0±0.)×(5.0±0.2) |
20 |
300/600 |
1000/2200 |
20/40 |
Storage/Operating Temperature : -20℃ to + 60℃
1.Are you the real manufacturer?
Yes. We are the real manufacturer since 1999.
2.What is your fiber brand?
Imported or Chinese brand
3.Can you accept small order?
Yes, small order is available .We support new project of our customers as we know business is always from small order.
4.What is your warranty period?
25 years for fiber optic cable
5.Which kind of certification you have ?
ISO9001, SGS, RoHs. ANTEL, CPR
6.What is your delivery time?
Usually within 2-3 working days
7.What about your annual production capacity?
Outdoor/Indoor Fiber Optic Cable, our annual output is 9,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.
8.What is your payment way?
T/T, L/C, D/P,MoneyGram,Western Union and Paypal.
9.Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.
