Cylinder Shaped Russian DC / AC Power Connectors Block Type Plug

Cylinder Shaped Russian DC / AC Power Connectors Block Type Plug thumbnail-1
Cylinder Shaped Russian DC / AC Power Connectors Block Type Plug thumbnail-2
Cylinder Shaped Russian DC / AC Power Connectors Block Type Plug photo-1
Cylinder Shaped Russian DC / AC Power Connectors Block Type Plug photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Contact Supplier Request Quote Chat Now
Novgorod Foundation For Small Business Support
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

2РМГ30Б32Ш1E2 Block-Type Plug

Сylinder-shaped, low-frequency connector intended for the operation in DC, AC (with a frequency of up to 3 MHz) and pulsed electrical circuits. 2РМГ - connector type, 30 - conventional body size, Б - body type: block, 32 - number of contacts, E - plug, 1 - index of contacts combination.

More than 50,000 items of goods are stock available and supplied on order.

Brand
Electrical connector - Urussu
Type of casing and fitting pipe
without casing
Country of origin
Russia
Contact resistance NMT
15 mΩ
Material
Steel, glass
Nominal voltage
560 V
Overall dimensions L*W*H
38х38х25 mm
Operating current
3 А - to the contact; 80 А - to the connector
Technical specifications
ГЕО.364.140ТУ
Insulation resistance
5000 mΩ
Functional group
Low-frequency, cylinder-shaped, sealed
Minimum run time at a temperature of max. +80°С
1500 h
Typical configuration
Block-Type Plug (Instrumental)
Operating temperature range
-60°C to +200°C
Contact type
circular
Relative humidity
98% at a temperature of +25°С
Number of outputs and contacts
32
Atmospheric pressure
1.34х10⁻¹⁰ Pa to 50.6х10⁴ Pa
Contact set reference number
1 - all contacts Ø 1 mm
Package
Box
Plating of outputs and contacts
E - electroless nickel
Minimum order
1 unit
Key Features

 - Circular
- Number of contacts: 32
- Contacts plating: E - electroless nickel
- Contact resistance: NMT 15 mΩ


- Nominal voltage: 560 V
- Operating current: 3 А - to the contact;
80 А - to the connector
- Connection method: threaded
- Mounting method: three-dimensional
Net weight of one unit
54.5 g
Package
Plastic bag + box
Box dimensions
Minimum dimensions 12*10*4cm
Box weight
Minimum weight 200g
Private Label Manufacturing
No
Minimum order
1 unit
The possible volume of supply
5,000 units per month
Delivery modes
Express courier, postal service, by sea, by truck
Our Company

IP Electron LLC
The IP Electron Company was founded in Velikiy Novgorod, the most ancient city in Russia that is situated between Moscow and Saint Petersburg, in 2007.

The history of the company's foundation began on the cusp of the 20th and 21st centuries, when, after the collapse of the USSR, a new country, the Russian Federation, came into existence and the country's economy began to move from a planned model to a market one. Due to the re-engineering of the electronic industry into the manufacture of more marketable products at the enterprises of the country, and at the North-West enterprises as well, a range of electronic components and devices was in low demand and sold out in wholesale numbers.

Thus, it became possible to purchase the radio components warehoused and make up a storage facility for radio-electronic components, this laid the foundation of the IP Electron Company. Currently, more than 50,000 items are stock available, this allows for the prompt delivery of RECs (connecting devices, relays, tumbler switches, electric motors, cable products, measuring devices, chips, LEDs, smd (chip) components, etc.).
For more than a decade of experience, we have established relationships with many manufacturers and key suppliers of radio-electronic components.

Cooperation with them allows us to carry out the wholesale distribution of goods and offer competitive prices.

Sales volume for the year 2018 was RUB23,000,000
We have been on the Russian market of electric components for 12 years
50,000 items of goods are stock available and supplied on order
More than 10,000 satisfied customers throughout the country
The company has a quality control system that ensures the reliability of products supplied and their further warranty!
Well-established logistics and availability of a large number of products at our own warehouse enable
us to deliver goods in the shortest possible time.
Our partners are oil-producing, mining and processing, machine building, metallurgical and other enterprises.
