Apparent Viscosity of Lubricating Greases Tester ASTM D1092
Product model: JF0681
Instrument introduction
This instrument mainly measures the apparent viscosity of grease, which is used to predict the pressure drop in the grease system at a specified temperature and steady flow.
Technical Parameter
1. Applicable standard: ASTM D1092 SH/T0681
2. Constant temperature method: external thermostat
3. Refrigeration method: imported compressor refrigeration
4. Temperature control: digital display PID temperature controller
5. Pressure display: pressure gauge
6. Pressure control: pressure regulating valve
7. Temperature control: ±0.1℃
8. Power supply: AC220V 50HZ
9. Power of the whole machine: 600W
Main Feature
1. The stainless steel sample tube is made of high-density processing, and it is equipped with a high-density piston;
2. Four separate pressure pipeline systems;
3. 8 sets of special capillary tubes, which meet the standard requirements;
4. Microcomputer temperature controller, digital display, PT100 temperature sensor, high
5. Integrated hydraulic pump, the flow is more stable;
6. Imported electric motor drive gearbox;
