1515 Replace Maxon Faulhaber 15mm BRUSHLES DC Hollow Cup Motor 12V Micro Motor Coreless dc Motor 1515RB

1515 Replace Maxon Faulhaber 15mm BRUSHLES DC Hollow Cup Motor 12V Micro Motor Coreless dc Motor 1515RB thumbnail-1
1515 Replace Maxon Faulhaber 15mm BRUSHLES DC Hollow Cup Motor 12V Micro Motor Coreless dc Motor 1515RB thumbnail-2
1515 Replace Maxon Faulhaber 15mm BRUSHLES DC Hollow Cup Motor 12V Micro Motor Coreless dc Motor 1515RB photo-1
1515 Replace Maxon Faulhaber 15mm BRUSHLES DC Hollow Cup Motor 12V Micro Motor Coreless dc Motor 1515RB photo-2
US$ 0.36 - 5.5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
kegumotor
Place of Origin:
China
Model Number:
KG-0408
Contact Supplier Request Quote Chat Now
Shen Zhen Ke Gu Technology Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/hongkong
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name kegumotor
Place of Origin China
Model Number KG-0408
Type Gear Motor
Certification CCC, CE, ROHS
Torque 5g.cm
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction Permanent Magnet
Efficiency IE 1
Protect Feature Explosion-proof
Voltage(V) 3
Output Power 0.01
Continuous Current(A) 0.01
Speed(RPM) 20000
Commutation Brush
Product Description
15mm daimeter ,15mm length 6v 12V coreless dc Micro Motor for toy ,Output shaft length: 5mm. Motor length: 15.2mm. Motor weight: 21. Coreless motor, little weight, small size, and efficiency. Gear Motor Stepper Motor Coreless Motor Brushless Motor ,steel Shaft Strong Magnet,15MM CORELESS MOTOR FOR ROTARY TATTOO MACHINE 10000RPM 12V DC MOTOR
Volt
5v
No Load Speed
25500rpm
Rated Speed
23000rpm
Rated Torque
5g.cm
Application
Robot , door lock , toy, cabinet lock, home appliance,vacuum cleaner
SPECIFICATION:

1. Voltage: DC 5V
2. No load speed: 25500±10%rpm
3. No load current: 0.1A
4. Diameter 15mm, length 15.2mm, shaft dia 1.0mm
5. Material: plastic gear and metal DC motor
6. Weight: 21g Approx
7. Application:Robot, Bike lock, Home Appliance, Door Lock etc
8. Customized,Adjust the performance at free(voltage, speed, torque)

  • Kegu Motor Provide intelligent lock solution

Special imported steel for gear material, minimum modulus (0.15 mode), ultra-low noise, high reliability.The motor adopts high
anti-oxidation commutator and brush material, which has
the characteristics of smooth operation, long life and small vibration.
* High Torque

* Low Noise

* Longer life time up to 200,000 times unlock
Working life
100 Hours
Voltage
DC 6V
No-load Current
0.01A
No-load Speed
21900 rpm
Load Current
0.02A
Load Speed
19068 rpm
Power
0.01 w
Load Torque
21 g.cm
Stall Current
0.09A
sall Torque
165g.cm
Warranty
1 year
MOQ
1000 pcs
Model Number
1718R 17mm x 18 mm  Mini CORELESS Motor
Price
USD 0.7-0.9
Application
mobile phone
Port
Shenzhen
Detailed Images
Size Information
Drawing of  15mm mini BLDC coreless motor,15mm Coreless Motor for Rotary Tattoo Machine 10000rpm 12V DC Motor
1.  Structure: Coreless Rotor +Permanent Magnet Stator+ metal brushes
2.  Size: Dia15*L15.2mm
3.  Shaft Dia: 1.0mm
4.  Certification: ISO9001, ROHS
5.  Endplay: 0.35mm Max
6.  Rotation: CW/CCW
7.  Voltage: 12 V dc .
8.  No load: 10000rpm 30mA
9.  Rated: 3.4mNm 0.3A 7600RPM
10. Stall: 14mNm
11. Shorter version, gearbox available
12. Long life, quiet, low vibration with high effieiceny
13. Ideal for tatoo gun, medical equipment

Custom specification is also available for us.

15mm Coreless Motor, 15mm Hollow Cup Motor, Coreless Motor for Tattoo Machine,Hollow Cup Motor for Tattoo Machine,Tatto Machine
Motor, Tatto Machine Coreless Motor, Tatto Machine Hollow Cup Motor,Coreless Motor Manufacturer, Coreless Motor Factory,Coreless
Motor China Shenzhen Manufacturer Factory,Customized Motor,Custom Motor,Custom Coreless Motor
1515R micor brush coreless dc motor Brand Kegumotor
Item 15mm mini BLDC vibration motor Location Shenzhen Model 1515r Load current 98mA Load power 1.2w Load volt
Load Torque 5G.cm Certificate ROHS/ISO9001 Application Blood pressure meter
Volt range 3.0-12V, no load speed :25500rpm

1515r coreless dc motor outline

Full range of precision gearbox, diameters 6mm,8mm,10mm,12mm,13mm,16mm,20mm,22mm,24mm,28mm,32mm,36mm,37mm,42mm,48mm, output speed 5-3000rpm,reduction ratio 5-1500, output torque 1g.cm to 50kg.cm
Recommended by seller
25mm 6v 12v 24v mini dc toy gear box motor with reduction gear for vending machines$2.27 - $7.50 / Piece1.0 Pieces
Micro 5rpm 10rpm 20rpm 50rpm mini gearbox 12mm Electric motor with N10 N20 N30 dc gear motor$7.00 / Piece2000 Pieces
180 degree shaft 20rpm ratio 250: 1 metal gearbox motor dc 12 volt gearbox motor small N20 dc gear motor with encoder$2.52 / Piece2 Pieces
KG-06P0610 dc 3v 6v 6mm plastic planetary gear motor with miniature plastic planetary gearhead$1.85 / Piece1 Piece
46mm 90 degree gearbox 5v micro dc worm geared motor with worm gearbox 6v 12v worm geared motor$3.57 - $7.50 / Piece1.0 Pieces
BL4260i bldc motor 42mm 12V 24V 4000rpm 6000rpm brushless dc motor built-in driver controller with hall sensor$9.20 - $22.00 / Piece1.0 Pieces
BL4260 dc 12v 18v 24v 100 200 250 300 watt 80kg.cm 90kg.cm 100kg.cm high torque 42mm brushless planetary gear motor$11.80 - $22.00 / Piece1.0 Pieces
Mini DC Gear Motor 12V 24V D Shaft 37mm Gearbox Motor Reduction Small Electric Motor with Encoder$3.00 - $7.50 / Piece50.0 Pieces
3V 6V 12V 24V 55rpm 95rpm 105rpm Planetary Gearbox DC Gear Motor 12mm High Torque Electric N20 Motor for Intelligent Lock$1.37 / Piece1 Piece
hot selling low noise small 4v m10 dc motor 10mm dc plastic gear motor with 10m plastic gearbox$0.95 / Piece1 Piece
micro brush 20mm vibrate FF-180 DC motor 3.3V Massager Vibrator Motor$0.30 - $3.90 / Piece1.0 Pieces
Packing&Shipping
After Sales Service
The reliability and stability of the product is an important index to evaluate the technical level of the product.In order to accurately analyze, evaluate and verify the performance of the product.
So Kegu motor will reply customer in 2 days after receive
complain from customer. Engineer team analyze the reasons according to customer complain and evaluate manufacturing process.After confirm the motor issue,customer can return defect motor, we will ship out all motors after repair motors.
Company Introduction
Shen Zhen Ke Gu Technology Co.,Ltd, it is a high-tech private enterprise integrating research, development, production and sales of various types of miniature DC motors, precision gearbox, micro transmission of system. We also provide the drive solutions for customers from design, components manufacturing and assembly.The company strictly implements the IS9001:2015 management system.
Products are widely used in automotive,communications equipment,smart home,medical equipment, intelligent security,household appliances,western kitchen equipment,machinery and electronics and other high-end transmission structures,products are exported to more than 50 countries and regions at home and abroad.
Our Services & Strength
R&D team is committed to designing and developing micro drive systems for many years and providing drive system solutions for customers.
Provide customized, design, development, production and assembly services of micro gear transmission system.
Certifications
FAQ
Q:1.What kind of motors you can provide?
A:Full range of precision gearbox, diameters 6mm,8mm,10mm,12mm,13mm,16mm,20mm,22mm,24mm,28mm,32mm,36mm,37mm,42mm,48mm, output speed 5-3000rpm,reduction ratio 5-1500, output torque 1g.cm to 50kg.cm

Q:2. Can you send me a price list?
A: For all of our motors, they are customized based on different requirements like lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your
detailed requirements and annual quantity, we'll see what offer we can provide.

Q:3. What's the lead time for regular order?
A: For orders, the standard lead time is 25-40 days and this time can be shorter or longer based on different model, period and quantity.

Q:4. Is it possible for you to develop new motors if we can provide tooling cost?
A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.

Q:5. Can I get some samples?
A: It depends. If only a few samples for personal use or replacement, I am afraid it'll be difficult for us to provide because all of our motors are custom made and no stock available if there is no further needs. If just sample testing before the official order and our MOQ, price and other terms are acceptable, we'd love to provide samples.
