AZ150 AL-ZN Zincalume / Galvalume Steel Sheets / Coil AFP SGCC Aluzinc Steel Coils
Product Description
Galvalume Steel Coil Sheet
Galvalume steel coil is coating with 55% aluminum, 43.4% zinc and 1.6% silicon by weight. The surface of the galvalume steel plate is uniquely smooth,with flat and gorgeous spangle, the base color is silver white. Has excellent corrosion resistance, has good processing performance, can be stamped,sheared, welded, surface conductivity is very good. The galvalume steel plate has superior corrosion resistance when exposed to the same environment on both sides compared to the same thickness of the galvanized steel sheet.
Specification
Product Type |
galvalume/aluzinc/zincalume/Al-Zn coating steel coil |
Surface |
silver white with flat spangle |
Coating |
55% aluminum, 43.4% zinc and 1.6% silicon |
Coating Weight |
AZ80,AZ100,AZ150 |
Steel Grade |
DX51D+AZ,SGLCC, NSDCC |
Dimension |
0.3mm-4mm x 1000mm/1220mm/1300mm/1500mm ; |
cut to size according to customers' demands |
|
Service |
OEM, customized processing service, customized fabrication by drawings |
Processing Type |
cutting, bending,stamping,welding,cnc machining |
Cutting Type |
laser cutting;water-jet cutting;flame cutting |
Features |
Good corrosion resistance,High heat reflectivity,Excellent adhesion |
Application |
Construction: roofs, walls, garages, soundproof walls etc. |
Automobile: muffler, exhaust pipe, wiper attachment, fuel tank etc. |
|
Home appliances: refrigerator back panel, gas stove, air conditioner etc. |
|
Agricultural: pig house, chicken house, granary, greenhouse pipes, etc. |
The role of aluminum, zinc, silicon
Aluminum, zinc :
A1<5%, A1↑→Corrosion resistance↑
5%~25%, A1↑→Corrosion resistance↓
A1>55%, the corrosion resistance is not significantly weakened, but some pitting corrosion appears. 55% A1 is the best and 25% A1 is the worst.
Silicon:
1. Inhibit the reaction between the steel strip and the bath melt
2. Inhibit the growth of aluminum-rich dendrites and improve the ability to resist peeling
3. "Heterogeneous nucleation"" to refine spangles
4. Reduce the viscosity of the plating solution and reduce the thickness of the alloy layer
5. Speed up the dissolution rate of the alloy layer
Product advantages
①Good corrosion resistance Under various environmental conditions, the galvanized steel sheet has excellent corrosion resistance than the hot-dip galvanized steel sheet of the same thickness, and its service life is 2-6 times that of the ordinary galvanized steel sheet. Since the microcracks of the aluminum-zinc-plated deformed parts are smaller than that of the hot-dip galvanizing, the corrosion resistance in the forming area is much higher than that of the hot-dip galvanizing.
②Good surface characteristics The surface characteristics are good, the spangles are small and uniform, the color is bright silver gray, and the surface hardness is high (not easy to scratch).
③Good processability The 55% aluminum-zinc alloy coated galvanized steel sheet has excellent adhesion and flexibility. It has excellent shape and workability similar to galvanized steel sheet. Especially, there are few cracks in the processing part on the steel sheet, and the durability of the processing part is excellent
④Good heat resistance The heat resistance of galvanized steel sheet is much better than that of galvanized steel sheet, and has the characteristics similar to that of aluminized steel sheet: Galvanized steel: It is recommended not to exceed 230℃ at high temperature, it will change color if it exceeds 250℃. Galvalume steel: The color does not change even when used for a long time at around 315℃, and it can also be used at around 370℃ for a short time.
④Good heat resistance The heat resistance of galvanized steel sheet is much better than that of galvanized steel sheet, and has the characteristics similar to that of aluminized steel sheet: Galvanized steel: It is recommended not to exceed 230℃ at high temperature, it will change color if it exceeds 250℃. Galvalume steel: The color does not change even when used for a long time at around 315℃, and it can also be used at around 370℃ for a short time.
⑤Good heat reflection The heat reflectivity of steel plate is about twice higher than that of galvanized steel plate, so when uncoated products are used on roof and partition wall panels,
better energy saving effect can be obtained.
better energy saving effect can be obtained.
Packing & Delivery
The sheets is packed with PVC film or water-proof kraft in the first layer, the second layer is
iron sheet package, then wrapped on the metal pallet or metal square tube with steel strip.
It's is water-proof and sea-worthy, and warmly welcomed by the customers.OEM accepted, besides, the pakage can also be according to your demands.
Company Profile
Tianjin Emerson Commercial and Trade Co.,Ltd mainly provides steel plate, steel sheet, steel pipe,seamless steel pipe and tube, round bars and steel section, and doing steel products processing service: steel plate and sheet processing service. The processing works concludes cutting the larger plate into the small sizes customer demand, cut by drawing, cut to special sizes, weld the cut parts by drawing, also make galvanizing processing or surface painting on the final processed parts; steel pipe hollow bar cutting and lathe processing to make the outer diameter and wall thickness to meet customers requirement, also make heat treatment for hollow bars and pipes. Tianjin Emerson Commercial and Trade Co.,Ltd has large stocks for the carbon steel and low alloy steel plates and sheets, especially have the thick plate and heavy plates on stock, also can provide the special material and large size steel plates, boiler and pressure vessel steel plate, marine steel plate, hot rolled steel plate for new production.
Our Servise
*1.Feedback: Any enquiry and comments will be feedback within 12 hours by email.
*2.Fast delivery,Guarantee.
*3.Common material stock available,we can also cuatomize product special material.
*4.Shipping photo: Shall offer the product photoes after loading into container. *5.Payment term: Both TT and L/C are acceptable.
*6.Documents: Offer all the relvant professional documents on time.
*7.Service: Give the feedback services after the buyer received the products by email.
If you have any inquiry, please kindly feel free to contact me
FAQ
Q: Will you accept the customized and OEM product?
A: Yes, we can do the production based on your drawings and with your logo; also
because we have very strong design and development team, so the feedback is very good for customized product.
because we have very strong design and development team, so the feedback is very good for customized product.
Q: How about the MOQ? If my first order qty is small, will you accept?
A: We would like to do our best to support your trial order qty, so even 1 pc or 1kg is ok to start cooperation; because we have confidence to move on second order with your esteemed company.
Q: What is your payment terms ?
A: Commonly two payment term for new customers:
1) 30% T/T as deposit , 70% balance against B/L copy;
2) 100% Irrevocable L/C at sight; If you need any other terms, pls feel free to contact us too, we will try our best.
Q: How long is your delivery time?
A: Our daily inventory is more than 8000 tons, so for common product size, just need 5 days from stocks; if the special size from new production, delivery 20-30 days.
Q: How about the samples ? is it free or extra fees?
A: Yes, we would like to supply the samples before order; if the samples from stock, it will be free; if the samples from new production, we will charge some reasonable cost, but this amount will be deducted from your first order invoice.
