Telecom, electric power, CCTV, railway, intelligent transportation, solar wind power, petrochemical engineering and other industries all need spd protection devices, our surge lightning protector supplier can provide surge protector arresters in line with the latest international and domestic standards.
Smart power surge protector SPD 40KA, mainly collects SPD damage status, air switch trip status, SPD false grounding, poor grounding, and SPD movement work times, configure standard RS485 interface data communication, support wired and wireless communication mode can provide custom programming interface. Smart outlet surge protector is convenient for electricians to connect with other private agreements.
Specification Of Smart SPD
Model |
M40B4-S |
Working Voltage: |
DC220V |
Power Consumption: |
2W |
Communication protocol: |
Standard MODBUS, MQTT protocol |
Max continuous operating voltage (Uc): |
385V |
Type Ⅰ maximum discharge current (Imax): |
20-40kA |
Type Ⅱ maximum discharge current (Imax): |
40-80kA |
Switch quantity acquisition: |
3 channels (remote signal, air switch, grounding) |
SPD operation counter: |
1 channel |
Counting range: |
0~9999 times |
Counting threshold: |
1 KA (factory default) |
Alarm indication: |
Red LED |
Constant light transmission distance: |
wireless (2500 m visible distance) |
IP protection level: |
IP20 |
Shell material: |
plastic |
Environmental humidity: |
|
Working temperature: |
-20~70 ℃ |
Dimensions: |
145*90*50mm (length, width, and height) |
Product weight: |
180 g |
Installation method: 35 mm rail |
35 mm Din rail |
Features Of Smart SPD
l No crash, adjustable starting threshold for accumulative counting, self-lightning protection, to ensure that it is not damaged by smart electrician surge protector
l 40kA/80kA SPD optional, support wired and wireless transmission
l The on-site alarm function can easily realize on-site management even if it is not connected to the Internet.
l Remote alarm function, through the cloud server, a remote monitor any data collection terminal, acquiring the real-time alarm information.
