Transversal and longitudinal cutting machine(CE approved)
Main Technical Parameter:
|
Model |
HX-500X+Y |
|
Voltage |
220V/380V |
|
Power |
1.5HP |
|
N.W. |
240kg |
|
G.W. |
260kg |
|
Cutting Length |
0.1~9999.9mm |
|
Cutting Width |
1~490mm |
|
Measurement |
980x1100x1150mm |
Features:
1. The max width: 500mm
2. Tolerence: 0.05mm, Precision: 0.1mm
3. Material thickness: 0.5mm-15mm
4. Kiss cut or cut through available
5. Under CE and ISO Certifications
6. Warranty for machine: 12months
7. Delivery time: 1-3days
Characteristics:
1. This machine employs microcomputer controller to set belt cutting length and width.
2. The cutting length is accurate.
3. Operation is easy.
4. Waste rate is low.
5. Manufacturing experience: 30 years
6. Export experience: 20 years
This machine employs microcomputer controller with the same basic cutting function as
HX-360/500B, has an extensional function to cut square shape.
Application: Sizing cutting for a variety of material and X+Y square
After-service:
1. Warranty for machines is 12 months
2. A promptly reply within 24 hours
3. Free usage training before delivering machines in factory
Packaging pictures:
