Automatic aluminium foil fold cutting machine
Main Technical Parameter for automatic aluminium foil fold cutting machine :
|
Model |
HX-500B |
|
Cutting Length |
0.1~9999.9mm |
|
Cutting Width |
1~500mm |
|
Power |
1000W |
|
Voltage |
220V/380V |
|
N.W./ GW. |
240/260kg |
|
Measurement |
980x1450x1070mm |
Machine configuration for automatic aluminium foil fold cutting machine :
|
Touch Screen |
WEINVIEW |
Made in Taiwan |
|
Programmable Controller |
MITSUBISHI |
Made in Japan |
|
Servo Driver |
DELTA |
Made in Taiwan |
|
Servo Motor |
DELTA |
Made in Taiwan |
|
Motor of cutting knife |
SL |
Made in Taiwan |
|
AC Contactor |
SNAIDER |
Made in China |
|
Solid State Relay 20A |
OMRON |
Made in Japan |
|
Electric eye (Optional) |
PANASONNIC SUNX |
Made in Japan |
Features for automatic aluminium foil fold cutting machine :
1. The max width: 500mm
2. Tolerence: 0.05mm, Precision: 0.1mm
3. Material thickness: 0.5mm-15mm
4. Kiss cut or cut through available
5. Under CE and ISO Certifications
6. Warranty for machine: 12months
7. Delivery time: 1-3days
8. Cut through for standard machine
9. Kiss cut is for optional
Characteristics for automatic aluminium foil fold cutting machine :
1. This machine employs man-machine interface + PLC system equipped with pneumatic pushing device.
2. For half cutoff with multi-cut, full cutoff with one-cut.
3. Five different cutting length can be set.
4. Different cutting quantity and circulation time also can be set to improve cutting efficiency.
5. The cutting length is accurate.
6. Operation is easy.
7. Waste rate is low.
8. Manufacturing experience: 30 years
9. Export experience: 20 years
Application for automatic aluminium foil fold cutting machine :
Sizing cutting for conductive fabric, foam, diffuser, reflector film, double-sided adhesive tape, nickel plate, PET, PC, PE insulation paper copper /aluminum foil and all kinds of adhesive tapes.
This machine applys to a variety of materials , includes but not limited to above .
If you are not sure whether this machine could be suitable for your material ,please inquiry us .
1. Warranty : 3 years (not includes consumable parts )
2. 24 Hours online service ,any technical problem could be solved timely.
3.Engineers available to service machinery overseas ,for Training and Maintenance .
4.Delivery time: 15-30 working days according to order quantity and model.
5.Payment term: 100%TT ,Westion Union ,Cash are all available .
6.All operation manual, operation interface offered in English.
7.If our machines can't well meet your requirment ,we support customized machine .
Our factory
workshop for automatic aluminium foil fold cutting machine
Our products on Shanghai World Expo
Customers Visiting our Factory
If you coming to visit our factory ,you will be warmly welcomed .
CE Certification
Our machines meet CE requirement . Conform to the safety, health, environmental protection and consumer protection, and a series of European directives to express requirements . For our products ,please rested assured .
Why choose us ?
1.We are factory for more than 10 years .We have steady and loyal supplier .So our components are high quality with low cost.
2.Our sales territory
Our machines have been exported to more than 40 countries .We have agent in South Korea .
Get quotation from us :
|
Items |
Information needed . |
|
Material name |
.......... |
|
Sheet or roll |
sheet /roll |
|
Number of layers |
1/2/3 |
|
Size |
diameter *width*thickness/ length*width *thickness |
|
Function you would like to realize. |
cutting /kiss cutting /die cutting /slitting /laminating |
|
Remark : |
............. |
With informations above ,quotation could be sent ASAP .
