UN38.3 Battery Pack Nail Penetration and Crush Tester
- 1000 per Month
- T/T Credit Card
Product Description
UN38.3 lithium ion battery crush tester
Inspect the safety performance of battery through squeeze test and the battery should not ignite or explode after test; it is also the essential inspection equipment of all battery manufacturers and research institutions.
Applicable Standards:
UL1642-2005, UL2054-2005, MT/T1051-2007, YD1268-2003, SJ/T 11170-1998, SJ/T11169-1998, GB/T 8897.4-2002, IEC 62133
Test method :
1 The battery are extruded between two plate, extrusion pressure applies with a diameter of 32 mm piston hydraulic pressure head, extrusion continues to hydraulic pressure head pressure readings reach to 17.2 M Pa, force is about 13 KN. Once reaching the maximum pressure, pressure can relieve.
2 Cylindrical ring prismatic battery needs to make its longitudinal axis parallel to the plane of the extrusion device to bear extrusion. The prismatic battery moves around its vertical axis rotation 90 degrees and places, so that the wide and narrow side can bear to the extrusion pressure. Each sample battery bears pressure as long as in a direction. Each test will use different samples.
3 The coin type or button type battery needs to make the battery plane parallel to the plane of the extrusion device to bear extrusion pressure.
Technical Parameters:
Pressure range |
1KN~15KN (standards for 13KN) |
Upper pressure plate diameter |
150mm (no less than 20 cm2) |
Force value error |
±1% |
Unit conversion |
Kg/N/Lb |
Test motive power mode |
Hydraulic pressure |
Test space |
W200 X D200 X H200mm |
View window size |
200 X 200mm (Double anti-explosion glass with thickness of 10mm) |
Exhaust fan outlet |
Diameter 150mm |
Lighting |
Equipped with a lighting lamp at the top inside the chamber body |
Test chamber external size |
W680X D570 X H1740(mm) |
Cabinet dimensions |
W330 X D330 X H1040(mm) |
Machine weight |
About 250Kg |
Rate of work |
1.5KW |
Power |
AC 380V/50HZ |
1.After an order is placed, when will you send to us?
Generally about 7 days, If we have it on stock, we can arrange shipment within 3 days.
2.What about the warranty with after - sales services?
12 months warranty. Besides, we can help you to repair your problem controller freely.
3.What about the services and product' quality?
Our products are widely recognized and trusted by users.All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other requireable standards.
if you have any question, pls contact us directly.
