Toughened film/glass Three four point bending tester
This machine is applicable to testing tensile stress, compressive stress, shearing force, peeling force, and elongation of materials, components, and finished product for metal, plastic, rubber, textile, synthetic chemicals, wire and cable, leather and so on..
1. Use Taiwan LEADSHINE step motor which ensures high efficiency, steady transmission and low noise. The accuracy of speed can be controlled in 2%.
2. The structure is made of the paint-coated aluminum blanking plate. The interior is used the high-accuracy, low-resistance and zero clearance of ball screw and oriented pole which improve loading efficiency and structure rigidity.
3. Using the brand computer as the main control machine, the special testing software can conduct all of testing parameter, work state, collecting data and analysis, result display and printing output.
Specifications
Capacity: 5KN,10KN,20KN,50KN,100KN..
Effective testing space:1000mm (enlarge available)
Effective width:400mm (enlarge available)
Displacement :resolution:0.001mm
Test speed: 20mm/min to 500mm/min
Load accuracy:0.5% F.S
Data display:Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc…
Curves display:Load- elongation, Elongation-time, Time-elongation, Stress-strain
Standards:
ASTM E8/E8M-13: "Standard Test Methods for Tension Testing of Metallic Materials"
ISO 6892-1: "Metallic materials. Tensile testing. Method of test at ambient temperature"
ISO 6892-2: "Metallic materials. Tensile testing. Method of test at elevated temperature"
JIS Z2241 Method of tensile test for metallic materials
ASTM D 3039/D 3039M: "Standard Test Method for Tensile Properties of Polymer Matrix Composite Materials"
ASTM D638 Standard Test Method for Tensile Properties of Plastics
1.After an order is placed, when will you send to us?
Generally about 7 days, If we have it on stock, we can arrange shipment within 3 days.
2.What about the warranty with after - sales services?
12 months warranty. Besides, we can help you to repair your problem controller freely.
3.What about the services and product' quality?
Our products are widely recognized and trusted by users.All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other requireable standards.
if you have any question, pls contact us directly.
Mob: 0086-13712874307
wechat/whatsapp:008613712874307
skype:Peter.liu560
