Textiles Linen Tracking Thermosticking Chip UHF Transponder RFID Laundry Tag

Name: Textiles Linen Tracking Thermosticking Chip UHF Transponder RFID Laundry Tag
Brand: HUAYUAN
Availability: InStock

FOB Price

US$ 0.25 - 0.5 / Piece

5000 Pieces(Min. Order)

Port Shanghai
Payment TermsT/T PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HUAYUAN		Place of Origin	China
Model Number	HLT Laundry Tag

Product Description

HUAYUAN HLT serial RAIN RFID laundry tag is a flexible, tenacious, heat resistant design transponder based on textile strip. All textile assets like flat linen, garments and uniforms can be traced and tracked imperceptibly conveyed with unique ID carried, to realize digital transparency and touchless laundry management throughout the soil collection, laundering, distribution processes by RFID facilities work with IT management systems. With a thin, narrow, and soft figure, the HLT laundry tag can be inserted into the tiny flat linen as well as finest textiles with no-wear feeling and unnoticeable look.

Key Features:

l Flexible, thin, smooth and robust;

l Long read range and bulk reading performance;

l Guaranteed for 200 washing cycles working through sterilization, dewater, heat iron processer under pressure 60 bars, 180°C heating;

l Fit for stitching, heat-sealing, pouching or hanging;

l On demand service: laser logo with EPC encoding in RFID chip.

Applications:

Textile Assets E-tracking Items: linen, uniforms, workwear, fire retardant, footwear, mask, mats, mops for healthcare, hotel, restaurant, even fashion apparel industries.

Specifications:

Protocol	ISO 18000-6C / EPC Global Class1 Gen2
Working Frequency	860 ~ 928MHz
IC	NXP UCODE 8, UCODE 9
Memory	UCODE 8: EPC 96/128bits, User 0/32bits, access password 32bits UCODE 9: EPC 96bits, User 0bits, access password 0bit
Write Endurance	100,000 times
Data Retention	20 years
Warranty	200 wash cycles or 2 years from ship date
Type	HLT-7015 / HLT-7015M
Size	70x15x1.6mm/1.1mm
Weight (approx.)	0.6g
Read Range	Up to 7m
Material and Components	l Substrate fabric: Terylene or 50/50 Terylene cotton l Antenna: Stainless fiber wrapped by TPU, l Chip modules alternative: 1, Dia. 5mm PCB board with near field antenna + QFN RFID chip + epoxy protection 2, 3.5x3.5x0.8mm mini cube with min antenna and chip sealed inside.
Typical Laundry Processes Cycles’ Endurance	Each of the 200 cycles industrial laundry under: l Sterilization: +134°C (273°F) / 20 minutes l Washing: +90°C (194°F) / 60 minutes l Water Extractor Press: 60 bars l Drying: +180°C (356°F) / 3 minutes (dehydration press: 35 bar) l Ironer: 195°C (383°F) / 30 seconds<18 bars
Storage Temperature	-40°C ~ +120°C (-40°F to +248°F)
Chemical Resistance	All chemicals common to the washing process
Certification	STANDARD 100 by OEKO-TEX / SGS
Variable Data	On demand variable data operation include visual data printing and chip programming serving based on customer’s individual request.

Installation:

HUAYUAN is a professional RFID tag providers. We provide kinds of RFID tag, RFID wristband, RFID card and so on. Want to know more? Please feel free contact us.
