High Output Wood Fuel Pellet Making Machine From CHINA

High Output Wood Fuel Pellet Making Machine From CHINA photo-1
High Output Wood Fuel Pellet Making Machine From CHINA photo-2
High Output Wood Fuel Pellet Making Machine From CHINA photo-3
High Output Wood Fuel Pellet Making Machine From CHINA photo-4
High Output Wood Fuel Pellet Making Machine From CHINA photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
2009
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Product Description

Description of Pellet Machine

This pellet machine is a vertical biomass pellets making machine which can be applied to press and form sawdust, peanut shell, bamboo shavings, bark, branches, cotton pole, maize straw, medical, mushroom residue, wine, furfural slag, industrial waste slag, etc.The mould is a ring die pressing mould with double layer. And finished pellets are of high density with smooth surface and good combustibility.

 High output wood fuel pellet making machine from CHINA

Features of Vertical Pellets Machine

1. PLC control, automatically detect the mold temperature, improve the production conditions, stable production operation.
2. Vertical feeding, full automatic.
3. Ring die made of special alloy steel mold, prolong the life of the mold, reduce the maintenance cost.
4. Full automatic intelligent detection system control feeding volume with uniform and reliable feed;
5. High output, low energy consumption, reasonable equipment structure design, good performance, excellent fatigue resistance, cost-effective.

High output wood fuel pellet making machine from CHINA

This pellets machine is a core equipment for the wood pelleting production line. Wood pellets production line includes the following machines: sawdust crusher, rotary dryer, belt conveyor, wood pellet machine, cooling machine and packing machine. It needs 3 staff for the operation of this production line.

The capacity of the wood pellets line can be from 0.5t/h to 8t/h. All capacity are available here, just tell us your requirment, and we will give the best solution for your pelleting project.

High output wood fuel pellet making machine from CHINAHigh output wood fuel pellet making machine from CHINA

Model of wood pellet machine:

Model Power (kw) Pellet Size Capacity t/h Size M Weight
HR450 55 4-12 0.3-1 2.2*0.9*1.6 3
HR550 75 4-12 0.7-1 2.3*1.1*1.78 5
HR560 90 4-12 1-1.5 2.6*1.3*2.3 6.3
HR680 160 4-12 2-2.5 3.2*1.4*2.4 8.5
Packaging & Shipping

We provide high quality wooden case for goods ,the machine is fully protected during transportation .

High output wood fuel pellet making machine from CHINAHigh output wood fuel pellet making machine from CHINA
