Help CenterChina Manufacturer 20khz Piezoelectric Ceramic 1000w Ultrasonic Transducer With Controller for Sale
Related Products
-
Piezo Ceramic Ultrasonic Transducer Used For Plastic Welding MachineNegotiableMOQ: 1 -
Piezoelectric Ceramic Ultrasonic Immersible TransducersNegotiableMOQ: 1
-
Good Price High Power Ultrasonic Transducer 40 KhzNegotiableMOQ: 1
-
500w 40 Khz Ultrasonic Piezoelectric TransducerNegotiableMOQ: 1
-
15K Piezoelectric Ceramic Ultrasonic Immersible TransducersNegotiableMOQ: 1
Ultrasonic device consists of ultrasonic transducer, booster, and work horn. The transducer is an energy converter, which can converted the high frequency. high power current, output of power supply into reciprocating mechanical energy of the ultrasonic vibration, the vibration frequency output of drive power with the same frequency as the current.
For welding and cutting, the most frequency is 15Khz and 20Khz, power here is between 1500W to 3600W, if you need higher, we can offer the double heads transducer, its power is 4200 WProduct Name | 1500W Ultrasonic Plastic Welding Machine 20KHz Ultrasonic Transducer |
Materia | stainless steel, aliminum alloy,ceramic,titanium alloy(customised) |
Type | 20Khz, 50-55cm of the diameter |
Brade | FYCG |
Service life | morn than 20000 hours |
Used | ultrasonic welder, ultrasonic plastic welding machine, ultrasonic reactor and so on |
High Power ultrasonic piezoelectric transducer manufacturers
1. Frequency: 19.50-20.10 Khz
2. Power: 1500W and 1800W, others customized
3.DIameter of shell: 50 mm, 55mm
4. Weight : 3.0 Kg
5. Material of booster: steel
6.Screw size: 3/8-24UNF, 1/2-20UNF
7. Application: PVC, PP, PE, PC, Resin, PC, PSU, PA and ets
Other Types of 20khz 1500W ultrasonic transducer:
20Khz ultrasonic transducer, 1800W Aluminum Alloy, Piezoelectric ceramic
20Khz ultrasonic transducer, 1500W, Aluminum Alloy, Piezoelectric ceramic
Our Workshop
Our Warehouse
Product Show
Service Team
Hangzhou Success Ultrasonic Equipment Co.,Ltd
Founded in 1995, with about 20 Years Experiences, from a small Transuder manufacture develop into a professional ultrasonic equipment manufacturer. we fousced on Design and Development of High Power Ultrasonic Products, FYCG supply ultrasonic core parts and technical support for ultrasonic complete equipment company, developing new style high-power ultrasonic applications. Our suctomers thoughout research institutions, universities, large and small enterprises. We also has a High-power Opening Ultrasonic Laboratory, has enough strength to provide superior solution.
Pre-sale Service
High power ultrasonic technology program design
1.strict mechnical processing requirements to ensure every product meet customer's remonds;
2. high automtic assembly processes to to ensure the consistency of parematers for each product
3.good aging test to enusre each product work stable and longer its service life
Humanized User experience
With 20 years design and produce experience
1. opening lab for testing the sample and doing experiment
2. supply ultrasonic conceptual design solution, creating the most value for customers
After-sales Service
1. 1 Year warranty
2. Installation and Debugging
3. Equipment operation training
4. Any problem will be responsed in 24 hours
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample and it's not free.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
HANGZHOU SUCCESS ULTRASONIC EQUIPMENT CO.,Ltd
Since 1995
Add: No. 16 South Shangsong Road, Yinhu Street, Fuyang District, Hangzhou City, Zhejiang Province, China(mainland)
Contact: Carol Yu
Any questions or requirement pls feel free to contact us, we will reply you within 24 hours.
