Hot Sell Linggao Good Quality 35kHz K745 High End High Frequency Plastic Sonotrode Full Automatic Welding Machine Manufacturer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2005
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Product L3000 Advanced 20kHz Ultrasonic Welding Machine Advanced Parts Exporters With Film Winding Machine Spot WeldingNegotiableMOQ: 1 -
Lingke Professional High Frequency Welding Machine Automatic Pcb Board Plastic Welder Steel Welding Seaming Machine for SaleNegotiableMOQ: 1
-
LINGKE Professional 2800W With Nice Ultrasonic FACTORY Soldering High Frequency Machine Plastics WelderNegotiableMOQ: 1
-
Price Professional LINGKE 2800w Nice Ultrasonic High Precision Soldering Embossing Machine Plastics WelderNegotiableMOQ: 1
-
Price Professional 35kHz 900W Ultrasonic Welding Machine Plastic WelderNegotiableMOQ: 1
Hot Sell Linggao Good Quality 35kHz K745 High End High Frequency Plastic sonotrode Full Automatic Welding Machine Manufacturer
* Dove-tail main column, no deflection during stroke movement.
* Programmable step control for air pressure.
* Optional travel measurement unit with accuracy ±0.01mm
* Optional pressure trigger unit and digital controller.
* Optional PC communication device for storing welding data, corresponding MES system and data tracking.
* Special program to check all switches on the press.
* CE operating mode is available.
* Programmable step control for air pressure.
* Optional travel measurement unit with accuracy ±0.01mm
* Optional pressure trigger unit and digital controller.
* Optional PC communication device for storing welding data, corresponding MES system and data tracking.
* Special program to check all switches on the press.
* CE operating mode is available.
Product Description
Product name | Ultrasonic Plastic Welding Machine | ||||||||||
Type | K745 High End | ||||||||||
Frequency | 35kHz | ||||||||||
Power | 900W | ||||||||||
Drive type | 40mm | ||||||||||
Drive energy | 7 bar maximum, 6 bar nominal | ||||||||||
Stroke range | 20-100mm | ||||||||||
Throatdepth | 170mm | ||||||||||
Height adjustment | 180mm | ||||||||||
Weight with generator | 51.5kg | ||||||||||
Company Profile
LINGKE ULTRASONICS CO., LTD
Originated in 1993, gradually developed into a National High-tech Enterprise with 10,000 square meters factory buildings, 70+ CNC processing equipment, 10+ assembly lines and various inspection instruments. As one of the earliest ultrasonic plastic welding machine manufacturers in China, we LINGKE ULTRASONICS CO., LTD has been committed to the research, development, production and sales of high performance ultrasonic plastic welding machines for more than 20 years.
With the professional and efficient R & D and production team, we have invented more than 100 professional new technologies and certified with ISO and CE certification. Strict quality control is carried out in all aspects from procurement, production, sales to after-sales service.
Our brands are "LINGKE", "LINGGAO" and "SHENGFENG". Mainly focus on the production of Ultrasonic Plastic Welding Machines, Spin Welding Machines, Hot Plate Welding Machines, Ultrasonic Welding System, Ultrasonic Cleaning Machines, Ultrasonic Horn, Fixture and Customized Equipment etc.. "LINGGAO" is an outstanding representative of the high-end ultrasonic plastic welding technology.
Lingke is a reliable partner to companies in various fields such as plastics, non-woven fabrics, packaging, printing consumables, medical, electronic appliances, automobiles, stationery, toys and daily necessities etc. A mass of high performance, cost effective and greatly stable welding machines and application solutions are provided to various industries and enterprises all over the world.
Great Ultrasonic Equipment, Lingke made.
Production Process
Sample room display
Exhibition
Why Choose Us
Packing & Delivery
Certifications
FAQ
1. Why choose ultrasonic welders?
A. It is cost effective, as it shortens manufacturing time.
B. It is environmentally-friendly, as no solvents, adhesives or any other reagent is needed.
C. It improves the quality of the products.
D. It ensures safety in production.
2. Is ultrasonic harmful to the human body?
No. Ultrasonic is a mechanical wave, and when it is propagating, the energy will concentrate on the same specific direction, and it will not cause harm to human body.
3. How to choose the Frequency of ultrasonic welders?
The material and size and other factors will be taken into consideration.
Please contact us, we will recommend the suitable machine according to your products.
4. What's your warranty terms?
Machines for one year.
5. Can you make customized horns (sonotrodes and fixtures) ?
We can make the customized horns according to your plastic parts.
6. What's the lead time?
If only conventional models, usually 3~10 working days.
If customized mold required, it needs negotiate.
