Stainless Steel SS316 V Type Ball Valve
US$ 200 - 500
MOQ: 110 Pieces
Key Specifications
Get Latest Price
Brand Name:
ZGPV
Place of Origin:
China
Model Number:
JNP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days
Related Products
-
Stainless Steel SS316L V Type Ball ValveUS$ 200 - 500MOQ: 110 Pieces -
Titanium V Type Ball ValveUS$ 200 - 500MOQ: 110 Pieces
-
Cast Steel Floating Ball ValveUS$ 200 - 2000MOQ: 10 Pieces
-
Carbon Steel Floating Ball ValveUS$ 200 - 2000MOQ: 10 Pieces
-
Duplex Stainless Steel Floating Ball ValveUS$ 200 - 2000MOQ: 10 Pieces
Brand Name
ZGPV
Place of Origin
China
Model Number
JNP
Material
Stainless Steel
Application
General
Structure
Ball
Standard or Nonstandard
Other, Non standard
Pressure
Low Pressure
Power
Hydraulic
Media
Water
Temperature of Media
Low Temperature
Brief introduction
| Product name: | Forged steel fully welded ball valve |
| DN: | 1/2"(15)~ 32"(800) |
| CLASS(PN): | 150LB(16)~600LB(2500) |
Application Standard
| Pressure temperature class: | ASME B16.34 |
| Design: | BS 5351, API 608, ASME B16.34, API 6D, GB, GOST, DIN, BS |
| Test: | API 6D / API 598 / GB / T 13927 and other relevant national standards. |
| Structure length: | API 6D, ANSI B16.10, GB 12221, GOST, DIN, BS / manufacturer standard / user requirements. |
| Connection end: | BW (ASME B16.25, ASME B31.8 and other national standards), RF(ASME B16.5, ASME B16.47, JB / HG / GOST, DIN, etc.), RTJ (ASME B16.5, ASME B16.47 , JB / HG / GOST, DIN, etc.), BW + PUP (the length of the transition tube is customized) |
| Fire protection requirements: | API 607/API 6FA/BS 6755 |
| Anti-static electricity: | API 608/BS 5351 |
| Valve anti-sulfur: | NACE MR. 0175 |
Structural features
| Body structure: | Bolted body, forged or cast steel |
| Valve seat: | Self-relieving / soft seat or hard seat |
| Ball: | Trunnion mounted,solid |
| Flow pass: | Full bore/ reduced diameter (optional) |
| Valve stem: | Anti-blowout, can be lengthened (optional) |
| Operation mode: | Manual / electric / pneumatic / pneumatic-hydraulic linkage / electro-hydraulic linkage / hydraulic (optional) |
| Seal: | Soft seal / composite seal (primary metal seal + secondary soft seal) |
| Grease injection valve: | Optional |
| Vent valve: | Optional |
| Sewage valve: | Optional |
| Locking device: | Optional |
| Bleeding valve: | No bleeding valve / single bleeding valve / double bleeding valve (optional). |
| Leak rating: | Soft seal: ISO 5208 Class A, metal seal: ISO 5208 Class C or higher, ANSI VI |
MOC
| Material of main parts | |
| Valve body | Carbon steel / stainless steel / alloy steel plate |
| Ball | Carbon steel / stainless steel / alloy steel forging nickel / chrome / spray welding hard alloy |
|
Support ring |
Carbon steel / stainless steel / alloy steel forging nickel / chrome / spray welding hard alloy |
| Valve seat | PTFE, RPTFE, NYLON, DEVLON, MOLON, PEEK/Seal face spray welding, tungsten carbide |
| Valve stem | Stainless steel / alloy steel / INCONEL, etc. |
| O ring | NR/HNBR/NBR/FKM/EPDM, etc. |
| Bolts and nuts | A193/A194, A320/GB/HG, etc. |
Product advantages
Can achieve equal percentage adjustment, large capacity, can be used for crystallization medium.
